6-15
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< CONNECTOR >
* CN301 1-580-756-21 PIN, CONNECTOR (SMD) 7P
CN931 1-691-520-11 CONNECTOR, BOARD TO BOARD 48P
CN933 1-779-893-11 PIN, CONNECTOR (PC BOARD) 8P
(TR517/TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
< DIODE >
D301 8-719-062-16 DIODE 01ZA8.2(TPL3)
D301 8-719-045-87 DIODE MA4Z082WA-(K8).SO
D302 8-719-421-27 DIODE MA728-(K8).S0
D304 8-719-073-03 DIODE MA8082-(K8).S0
D305 8-719-056-89 DIODE MA8120-TX
D306 8-719-078-02 DIODE 1SS357(T3SONY1)
D308 8-719-078-02 DIODE 1SS357(T3SONY1)
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
D310 8-719-078-02 DIODE 1SS357(T3SONY1)
D311 8-719-078-02 DIODE 1SS357(T3SONY1)
D312 8-719-078-02 DIODE 1SS357(T3SONY1)
(TR517/TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
D312 8-719-027-76 DIODE 1SS357-TPH3 (TR517)
D313 8-719-078-02 DIODE 1SS357(T3SONY1)
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
< FUSE >
0 F302 1-576-406-21 FUSE, MICRO (1608) (1.4A)
0 F303 1-576-406-21 FUSE, MICRO (1608) (1.4A)
0 F304 1-576-406-21 FUSE, MICRO (1608) (1.4A)
0 F305 1-576-406-21 FUSE, MICRO (1608) (1.4A)
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
0 F306 1-576-406-21 FUSE, MICRO (1608) (1.4A)
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
< FERRITE BEAD >
FB310 1-500-238-22 FERRITE 0UH
FB320 1-500-238-22 FERRITE 0UH (TR517)
FB321 1-500-238-22 FERRITE 0UH
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
< IC >
IC301 8-752-090-20 IC CXA3057R-T6
< COIL >
L301 1-416-670-11 INDUCTOR 33uH
L302 1-416-669-11 INDUCTOR 22uH
L303 1-412-056-11 INDUCTOR 4.7uH
L304 1-416-669-11 INDUCTOR 22uH
L305 1-416-670-11 INDUCTOR 33uH
L306 1-416-669-11 INDUCTOR 22uH
L307 1-412-056-11 INDUCTOR 4.7uH
L308 1-412-056-11 INDUCTOR 4.7uH
L309 1-412-056-11 INDUCTOR 4.7uH
L313 1-414-400-41 INDUCTOR 22uH
L314 1-412-056-11 INDUCTOR 4.7uH
L315 1-414-400-41 INDUCTOR 22uH
L316 1-412-056-11 INDUCTOR 4.7uH
L317 1-414-400-41 INDUCTOR 22uH
L318 1-416-669-11 INDUCTOR 22uH
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
L319 1-412-056-11 INDUCTOR 4.7uH
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
< TRANSISTOR >
Q301 8-729-047-68 TRANSISTOR 2SK1830-TE85L
0 Q302 8-729-046-77 TRANSISTOR SI4963DY-T1
Q303 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q304 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q305 8-729-047-68 TRANSISTOR 2SK1830-TE85L
Q307 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q308 8-729-046-98 TRANSISTOR CPH6702-TL
Q309 8-729-046-98 TRANSISTOR CPH6702-TL
Q310 8-729-046-98 TRANSISTOR CPH6702-TL
Q311 8-729-046-98 TRANSISTOR CPH6702-TL
Q312 8-729-046-98 TRANSISTOR CPH6702-TL
Q313 8-729-044-58 TRANSISTOR SI2304DS-T1
Q316 8-729-046-98 TRANSISTOR CPH6702-TL
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
Q317 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q318 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q319 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q320 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q321 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q322 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q323 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q325 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q327 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
Q328 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
Q329 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q330 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q331 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q332 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
Q333 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
< RESISTOR >
R301 1-216-837-11 METAL CHIP 22K 5% 1/16W
R302 1-216-839-11 METAL CHIP 33K 5% 1/16W
R303 1-216-821-11 METAL CHIP 1K 5% 1/16W
R304 1-216-839-11 METAL CHIP 33K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
R305 1-216-837-11 METAL CHIP 22K 5% 1/16W
DD-134
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
