6-16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R306 1-216-821-11 METAL CHIP 1K 5% 1/16W
R307 1-216-864-11 METAL CHIP 0 5% 1/16W
R309 1-216-853-11 METAL CHIP 470K 5% 1/16W
R310 1-216-857-11 METAL CHIP 1M 5% 1/16W
R311 1-216-813-11 METAL CHIP 220 5% 1/16W
R312 1-216-839-11 METAL CHIP 33K 5% 1/16W
R313 1-216-150-91 RES-CHIP 10 5% 1/8W
R314 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R315 1-216-837-11 METAL CHIP 22K 5% 1/16W
R316 1-216-821-11 METAL CHIP 1K 5% 1/16W
R317 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R318 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
R319 1-216-841-11 METAL CHIP 47K 5% 1/16W
R322 1-216-296-91 SHORT 0
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
R323 1-216-841-11 METAL CHIP 47K 5% 1/16W
R324 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R325 1-216-841-11 METAL CHIP 47K 5% 1/16W
R326 1-216-837-11 METAL CHIP 22K 5% 1/16W
R327 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
R328 1-218-871-11 METAL CHIP 10K 0.5% 1/16W
R329 1-216-845-11 METAL CHIP 100K 5% 1/16W
R330 1-216-864-11 METAL CHIP 0 5% 1/16W
R331 1-216-864-11 METAL CHIP 0 5% 1/16W
R332 1-218-877-11 METAL CHIP 18K 0.5% 1/16W
R333 1-216-837-11 METAL CHIP 22K 5% 1/16W
R335 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
R336 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
(TRV87/TRV87P)
R336 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
(TR317/TR517/TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R337 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
(TRV87/TRV87P)
R337 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR317/TR517/TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R338 1-218-903-11 METAL CHIP 220K 0.5% 1/16W
R339 1-216-845-11 METAL CHIP 100K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
R340 1-216-841-11 METAL CHIP 47K 5% 1/16W
R341 1-216-845-11 METAL CHIP 100K 5% 1/16W
R342 1-216-845-11 METAL CHIP 100K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
R343 1-216-837-11 METAL CHIP 22K 5% 1/16W
R344 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
R345 1-218-903-11 METAL CHIP 220K 0.5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
R346 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
R347 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R348 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R349 1-218-877-11 METAL CHIP 18K 0.5% 1/16W
(TRV87/TRV87P)
R349 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR317/TR517/TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R354 1-216-833-91 RES-CHIP 10K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
R357 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
R358 1-218-871-11 METAL CHIP 10K 0.5% 1/16W
< TRANSFORMER >
0 T301 1-435-252-21 TRANSFORMER, DC-DC CONVERTER
************************************************************
A-7074-162-A EJ-29 BOARD, COMPLETE (TR317/TR517)
**********************************
(Ref.No.;1000 Series)
< CONNECTOR >
CN251 1-766-346-21 CONNECTOR, FFC/FPC 16P
CN252 1-764-709-11 CONNECTOR, FFC/FPC 10P
CN253 1-764-703-11 CONNECTOR, FFC/FPC (LIF) 4P
< DIODE >
D253 8-719-062-16 DIODE 01ZA8.2(TPL3)
D256 8-719-073-01 DIODE MA111-TX
D257 8-719-073-01 DIODE MA111-TX
< FERRITE BEAD >
FB251 1-500-238-22 FERRITE 0UH
FB252 1-500-238-22 FERRITE 0UH
FB253 1-500-238-22 FERRITE 0UH
< JACK >
J251 1-565-276-31 JACK, ULTRA SMALL 1P (lLANC)
< RESISTOR >
R251 1-216-821-11 METAL CHIP 1K 5% 1/16W
R252 1-216-821-11 METAL CHIP 1K 5% 1/16W
R253 1-216-821-11 METAL CHIP 1K 5% 1/16W
R254 1-216-821-11 METAL CHIP 1K 5% 1/16W
R255 1-216-821-11 METAL CHIP 1K 5% 1/16W
R256 1-216-821-11 METAL CHIP 1K 5% 1/16W
R257 1-216-821-11 METAL CHIP 1K 5% 1/16W
R258 1-216-821-11 METAL CHIP 1K 5% 1/16W
R259 1-216-029-00 METAL CHIP 150 5% 1/10W
< SWITCH >
S251 1-771-331-21 SWITCH, PUSH (1 KEY) (EJECT
.
)
************************************************************
DD-134 EJ-29
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
