6-17
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
FP-249 FP-355
A-7074-149-A EJ-30 BOARD, COMPLETE
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
**************************************
(Ref.No.;1000 Series)
< CONNECTOR >
CN251 1-766-346-21 CONNECTOR, FFC/FPC 16P
CN252 1-764-709-11 CONNECTOR, FFC/FPC 10P
CN253 1-764-703-11 CONNECTOR, FFC/FPC (LIF) 4P
< DIODE >
D253 8-719-062-16 DIODE 01ZA8.2(TPL3)
D256 8-719-073-01 DIODE MA111-TX
D257 8-719-073-01 DIODE MA111-TX
< FERRITE BEAD >
FB251 1-414-228-11 INDUCTOR CHIP 0UH
FB252 1-414-228-11 INDUCTOR CHIP 0UH
FB253 1-414-228-11 INDUCTOR CHIP 0UH
< JACK >
J251 1-565-276-31 JACK, ULTRA SMALL 1P (lLANC)
< RESISTOR >
R251 1-216-821-11 METAL CHIP 1K 5% 1/16W
R252 1-216-821-11 METAL CHIP 1K 5% 1/16W
R253 1-216-821-11 METAL CHIP 1K 5% 1/16W
R254 1-216-821-11 METAL CHIP 1K 5% 1/16W
R255 1-216-821-11 METAL CHIP 1K 5% 1/16W
R256 1-216-821-11 METAL CHIP 1K 5% 1/16W
R257 1-216-821-11 METAL CHIP 1K 5% 1/16W
R258 1-216-821-11 METAL CHIP 1K 5% 1/16W
R259 1-216-029-00 METAL CHIP 150 5% 1/10W
< SWITCH >
S251 1-771-331-21 SWITCH, PUSH (1 KEY) (EJECT)
************************************************************
FP-249 MOUNT (Not supplied)
************************
(Ref.No.;1000 Series)
3-965-552-01 HOLDER (T), SENSOR
< HOLE ELEMENT >
H001 8-719-061-28 DIODE HW-105C-FT-V (S REEL)
H002 8-719-061-28 DIODE HW-105C-FT-V (T REEL)
< TRANSISTOR >
Q001 8-729-907-25 PHOTO TRANISTOR PT4850F (TAPE TOP)
< SWITCH >
S001 1-692-614-11 SWITCH, PUSH (3 KEY)
(Hi8 MP,ME/MP,REC PROOF)
************************************************************
1-658-213-11 FP-355 FLEXIBLE BOARD
********************
(Ref.No.;1000 Series)
< DIODE >
D001 8-719-988-42 DIODE GL453
************************************************************
1-658-214-11 FP-356 FLEXIBLE BOARD
********************
(Ref.No.;1000 Series)
3-965-551-01 HOLDER (S), SENSOR
< TRANSISTOR >
Q002 8-729-907-25 PHOTO TRANISTOR PT4850F (TAPE END)
************************************************************
A-7074-192-A LB-62 BOARD, COMPLETE (TR517)
****************************
(Ref.No.;1000 Series)
< CAPACITOR >
C4601 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C4602 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C4603 1-115-464-91 CERAMIC CHIP 0.0022uF 10% 630V
C4604 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN4601 1-764-516-21 CONNECTOR, FFC/FPC (ZIF) 6P
< IC >
IC4601 8-759-485-79 IC TC7SET08FU(TE85R)
< COIL >
L4601 1-412-031-11 INDUCTOR CHIP 47uH
L4602 1-469-525-91 INDUCTOR 10uH
< FLUORESCENT INDICATOR >
0 ND4601 1-517-933-11 FLUORESCENT TUBE (0.44)
< TRANSISTOR >
Q4601 8-729-039-24 TRANSISTOR FX216-TL1
< RESISTOR >
R4601 1-216-808-11 METAL CHIP 82 5% 1/16W
R4604 1-216-853-11 METAL CHIP 470K 5% 1/16W
< TRANSFORMER >
0 T4601 1-435-225-21 TRANSFORMER, INVERTER
************************************************************
EJ-30 FP-356 LB-62
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
