Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7074-153-A MA-374 BOARD, COMPLETE (TR317/TR517)
***********************************
(Ref.No.;1000 Series)
< CAPACITOR >
C322 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C325 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C330 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C333 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C336 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C341 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C342 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C353 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C354 1-104-851-11 TANTAL. CHIP 10uF 20% 4V
C356 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C357 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C358 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C359 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C360 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CN301 1-695-320-21 PIN, CONNECTOR (1.5MM)(SMD) 2P
CN303 1-779-334-11 CONNECTOR, FFC/FPC 20P
< DIODE >
D302 8-719-060-65 DIODE DAC3810
D303 8-719-067-44 DIODE CL-310IRS-X-TU
D304 8-719-061-82 DIODE TLSU1002(TPX1,SONY)
D305 8-719-073-01 DIODE MA111-TX
D323 8-719-073-01 DIODE MA111-TX
< FUSE >
0 F301 1-533-874-11 FUSE, MICRO (0.2A)
< IC >
IC322 8-759-339-63 IC NJM2118V-TE2
< JACK >
J321 1-568-027-11 JACK, SMALL TYPE (MIC)
< COIL >
L301 1-216-295-91 SHORT 0 (Note)
< TRANSISTOR >
Q301 8-729-402-42 TRANSISTOR UN5213-TX
Q302 8-729-422-51 TRANSISTOR UN5110-QRS-TX
Q304 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
Q321 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q322 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
< RESISTOR >
R304 1-216-864-11 METAL CHIP 0 5% 1/16W
R305 1-216-817-11 METAL CHIP 470 5% 1/16W
R307 1-216-815-11 METAL CHIP 330 5% 1/16W
R308 1-216-309-00 METAL CHIP 5.6 5% 1/10W
R309 1-216-302-00 METAL CHIP 2.7 5% 1/10W
R310 1-216-864-11 METAL CHIP 0 5% 1/16W
R312 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R313 1-216-864-11 METAL CHIP 0 5% 1/16W
R322 1-216-864-11 METAL CHIP 0 5% 1/16W
R323 1-216-864-11 METAL CHIP 0 5% 1/16W
R327 1-216-864-11 METAL CHIP 0 5% 1/16W
R328 1-216-817-11 METAL CHIP 470 5% 1/16W
R332 1-216-841-11 METAL CHIP 47K 5% 1/16W
R333 1-216-841-11 METAL CHIP 47K 5% 1/16W
R335 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R340 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R341 1-216-834-11 METAL CHIP 12K 5% 1/16W
R344 1-216-834-11 METAL CHIP 12K 5% 1/16W
R345 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R346 1-216-838-11 METAL CHIP 27K 5% 1/16W
R347 1-216-838-11 METAL CHIP 27K 5% 1/16W
R348 1-216-837-11 METAL CHIP 22K 5% 1/16W
R349 1-216-837-11 METAL CHIP 22K 5% 1/16W
R358 1-216-803-11 METAL CHIP 33 5% 1/16W
< SWITCH >
S302 1-771-331-51 SWITCH, PUSH (1 KEY) (VTR/PLAYER)
S303 1-771-331-71 SWITCH, PUSH (1 KEY) (CAMERA)
************************************************************
A-7074-127-A MA-375 BOARD, COMPLETE (TRV87/TRV87P)
************************************
A-7074-121-A MA-375 BOARD, COMPLETE
(TRV57/TRV57P/TRV67)
**************************************
A-7074-228-A MA-375 BOARD, COMPLETE (TRV17/TRV37)
***********************************
A-7074-191-A MA-375 BOARD, COMPLETE (TRV47)
*****************************
(Ref.No.;1000 Series)
< CAPACITOR >
C301 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
(TRV87/TRV87P)
C302 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C303 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C304 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C305 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C322 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV87/TRV87P)
C325 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C326 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C327 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
(TRV87/TRV87P)
MA-374 MA-375
Note : Resistor is mounted to the location where L301 is printed.
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ver 1.2 2000. 11
