Sony CCD-TR317 - Page 200

6-19
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C328 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
(TRV87/TRV87P)
C329 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C330 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C331 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV87/TRV87P)
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV87/TRV87P)
C333 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C334 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C335 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C336 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C337 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C338 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C339 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
(TRV87/TRV87P)
C340 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
(TRV87/TRV87P)
C341 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C342 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C343 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(TRV87/TRV87P)
C344 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(TRV87/TRV87P)
C345 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(TRV87/TRV87P)
C346 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(TRV87/TRV87P)
C347 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(TRV87/TRV87P)
C348 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(TRV87/TRV87P)
C349 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(TRV87/TRV87P)
C350 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(TRV87/TRV87P)
C351 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(TRV87/TRV87P)
C352 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(TRV87/TRV87P)
C353 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C354 1-104-851-11 TANTAL. CHIP 10uF 20% 4V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C355 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV87/TRV87P)
C356 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C357 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C358 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C359 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C360 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
C362 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
(TRV87/TRV87P)
C363 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
(TRV87/TRV87P)
C364 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
(TRV87/TRV87P)
< CONNECTOR >
* CN301 1-695-320-21 PIN, CONNECTOR (1.5MM)(SMD) 2P
* CN302 1-695-320-21 PIN, CONNECTOR (1.5MM)(SMD) 2P
(TRV87/TRV87P)
CN303 1-779-334-11 CONNECTOR, FFC/FPC 20P
< DIODE >
D301 8-719-078-23 DIODE DCR2815 (TRV87/TRV87P)
D302 8-719-060-65 DIODE DAC3810
D303 8-719-067-44 DIODE CL-310IRS-X-TU
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
D304 8-719-061-82 DIODE TLSU1002(TPX1,SONY)
D305 8-719-073-01 DIODE MA111-TX
D322 8-719-073-03 DIODE MA8082-(K8).S0 (TRV87/TRV87P)
D323 8-719-073-01 DIODE MA111-TX
< FUSE >
0 F301 1-533-874-11 FUSE, MICRO (0.2A)
< IC >
IC301 8-749-012-83 IC PNA4S13M01S0
(TRV47/TRV57/TRV57P/TRV67/TRV87/TRV87P)
IC321 8-759-643-77 IC BH7870KV-E2 (TRV87/TRV87P)
IC322 8-759-339-63 IC NJM2118V-TE2
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
< JACK >
J321 1-568-027-11 JACK, SMALL TYPE (MIC)
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
J321 1-691-737-11 JACK SMALL TYPE (MIC) (TRV87/TRV87P)
< COIL >
L301 1-414-754-11 INDUCTOR 10uH (TRV87/TRV87P)
L301 1-216-295-91 SHORT 0 (Note)
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
< TRANSISTOR >
Q301 8-729-402-42 TRANSISTOR UN5213-TX
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
Q302 8-729-422-51 TRANSISTOR UN5110-QRS-TX
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
Q302 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
(TRV87/TRV87P)
Q303 8-729-026-48 TRANSISTOR 2SA1037AK-T146-Q
(TRV87/TRV87P)
Q304 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
MA-375
Note : Resistor is mounted to the location where L301 is printed.
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
