6-20
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Q321 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
Q322 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
< RESISTOR >
R301 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(TRV87/TRV87P)
R302 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV87/TRV87P)
R303 1-216-810-11 METAL CHIP 120 5% 1/16W
(TRV87/TRV87P)
R304 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R305 1-216-817-11 METAL CHIP 470 5% 1/16W
R306 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV87/TRV87P)
R307 1-216-815-11 METAL CHIP 330 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R308 1-216-309-00 METAL CHIP 5.6 5% 1/10W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R308 1-216-311-00 METAL CHIP 6.8 5% 1/10W
(TRV87/TRV87P)
R309 1-216-302-00 METAL CHIP 2.7 5% 1/10W
R310 1-216-864-11 METAL CHIP 0 5% 1/16W
R312 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R313 1-216-864-11 METAL CHIP 0 5% 1/16W
R314 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
R315 1-216-847-11 METAL CHIP 150K 5% 1/16W
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
R321 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV87/TRV87P)
R322 1-216-864-11 METAL CHIP 0 5% 1/16W
R323 1-216-864-11 METAL CHIP 0 5% 1/16W
R324 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV87/TRV87P)
R325 1-216-839-11 METAL CHIP 33K 5% 1/16W
(TRV87/TRV87P)
R326 1-216-836-11 METAL CHIP 18K 5% 1/16W
(TRV87/TRV87P)
R327 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R328 1-216-817-11 METAL CHIP 470 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R329 1-216-833-91 RES-CHIP 10K 5% 1/16W
(TRV87/TRV87P)
R331 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(TRV87/TRV87P)
R332 1-216-841-11 METAL CHIP 47K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R333 1-216-841-11 METAL CHIP 47K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R334 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(TRV87/TRV87P)
R335 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R336 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(TRV87/TRV87P)
R337 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(TRV87/TRV87P)
R338 1-216-821-11 METAL CHIP 1K 5% 1/16W
(TRV87/TRV87P)
R339 1-216-821-11 METAL CHIP 1K 5% 1/16W
(TRV87/TRV87P)
R340 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R341 1-216-834-11 METAL CHIP 12K 5% 1/16W
R342 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
(TRV87/TRV87P)
R343 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
(TRV87/TRV87P)
R344 1-216-834-11 METAL CHIP 12K 5% 1/16W
R345 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R346 1-216-838-11 METAL CHIP 27K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R347 1-216-838-11 METAL CHIP 27K 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R348 1-216-837-11 METAL CHIP 22K 5% 1/16W
R349 1-216-837-11 METAL CHIP 22K 5% 1/16W
R350 1-216-836-11 METAL CHIP 18K 5% 1/16W
(TRV87/TRV87P)
R351 1-216-836-11 METAL CHIP 18K 5% 1/16W
(TRV87/TRV87P)
R352 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV87/TRV87P)
R353 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(TRV87/TRV87P)
R354 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(TRV87/TRV87P)
R355 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV87/TRV87P)
R356 1-216-839-11 METAL CHIP 33K 5% 1/16W
(TRV87/TRV87P)
R357 1-216-839-11 METAL CHIP 33K 5% 1/16W
(TRV87/TRV87P)
R358 1-216-803-11 METAL CHIP 33 5% 1/16W
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
R359 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
(TRV87/TRV87P)
R360 1-216-839-11 METAL CHIP 33K 5% 1/16W
(TRV87/TRV87P)
R361 1-216-836-11 METAL CHIP 18K 5% 1/16W
(TRV87/TRV87P)
R362 1-216-818-11 METAL CHIP 560 5% 1/16W
(TRV87/TRV87P)
R363 1-216-833-91 RES-CHIP 10K 5% 1/16W
(TRV87/TRV87P)
R364 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV87/TRV87P)
R365 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV87/TRV87P)
< SWITCH >
S301 1-692-605-11 SWITCH, SLIDE
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
S302 1-771-331-51 SWITCH, PUSH (1 KEY)(VTR/PLAYER)
S303 1-771-331-71 SWITCH, PUSH (1 KEY)(CAMERA)
************************************************************
MA-375
Ver 1.2 2000. 11
