6-27
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
VC-234
C777 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV87/TRV87P)
C778 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV87/TRV87P)
C781 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
(TRV87/TRV87P)
C801 1-115-156-11 CERAMIC CHIP 1uF 10V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C802 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C803 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C804 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C805 1-162-638-11 CERAMIC CHIP 1uF 16V
C806 1-119-749-11 TANTAL. CHIP 33uF 20% 4V
C807 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C809 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C810 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C813 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C814 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C815 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C817 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C818 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C819 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C820 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C821 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C822 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C823 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C824 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C825 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C826 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C901 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C902 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C903 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C904 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C907 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C908 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C909 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C910 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C911 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C912 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C913 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C914 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C915 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C971 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C972 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C973 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C974 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-766-346-21 CONNECTOR, FFC/FPC 16P
CN501 1-779-331-11 CONNECTOR, FFC/FPC 14P
CN551 1-691-362-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN971 1-766-352-21 CONNECTOR, FFC/FPC 22P
CN972 1-766-350-21 CONNECTOR, FFC/FPC 20P
CN973 1-766-340-21 CONNECTOR, FFC/FPC 10P
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
CN974 1-766-644-21 CONNECTOR, FFC/FPC 8P
CN975 1-785-760-11 CONNECTOR, FFC/FPC (ZIF) 45P
CN976 1-766-340-21 CONNECTOR, FFC/FPC 10P
CN977 1-766-336-21 CONNECTOR, FFC/FPC 6P (TRV87/TRV87P)
CN978 1-766-342-21 CONNECTOR, FFC/FPC 12P
CN979 1-766-345-21 CONNECTOR, FFC/FPC 15P
CN980 1-766-346-21 CONNECTOR, FFC/FPC 16P
CN981 1-691-542-21 CONNECTOR, BOARD TO BOARD48P
CN982 1-766-346-21 CONNECTOR, FFC/FPC 16P
< DIODE >
D201 8-719-055-86 DIODE KV1470TL1-3
D202 8-719-055-86 DIODE KV1470TL1-3
D203 8-719-027-76 DIODE 1SS357-TPH3 (TRV87/TRV87P)
D401 8-719-075-12 DIODE MA3XD21001S0
D501 8-713-103-84 DIODE 1T379-01-T8A
D502 8-719-073-01 DIODE MA111-TX
(TR317/TR517/TRV17/TRV37/TRV47)
D551 8-719-073-01 DIODE MA111-(K8).S0
D801 8-719-073-01 DIODE MA111-(K8).S0
D802 8-719-073-01 DIODE MA111-(K8).S0
D803 8-719-073-01 DIODE MA111-(K8).S0
D804 8-719-073-01 DIODE MA111-(K8).S0
D971 8-719-073-03 DIODE MA8082-(K8).S0
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
D972 8-719-062-16 DIODE 01ZA8.2(TPL3)
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
D973 8-719-073-03 DIODE MA8082-(K8).S0 (TRV87/TRV87P)
< FERRITE BEAD >
FB101 1-414-228-11 INDUCTOR CHIP 0UH
FB102 1-414-228-11 INDUCTOR CHIP 0UH
FB201 1-500-238-22 FERRITE 0UH
FB202 1-500-238-22 FERRITE 0UH (TRV87/TRV87P)
FB203 1-500-238-22 FERRITE 0UH
FB204 1-500-238-22 FERRITE 0UH
FB205 1-500-238-22 FERRITE 0UH
FB206 1-500-238-22 FERRITE 0UH (TRV87/TRV87P)
FB207 1-500-238-22 FERRITE 0UH
FB291 1-500-238-22 FERRITE 0UH
FB501 1-500-238-22 FERRITE 0UH
FB502 1-216-864-11 METAL CHIP 0 5% 1/16W
(Note)
FB503 1-500-284-21 INDUCTOR CHIP 0UH
FB504 1-500-238-22 FERRITE 0UH
FB505 1-216-864-11 METAL CHIP 0 5% 1/16W
(Note)
FB506 1-500-238-22 FERRITE 0UH
(TR317/TR517/TRV17/TRV37/TRV47)
FB641 1-500-238-22 FERRITE 0UH
FB801 1-500-238-22 FERRITE 0UH
FB901 1-500-238-22 FERRITE 0UH
Note : Resistors are mounted to the location where FB502,FB505
are printed.
