Sony CCD-TR317 - Page 223

Page
6-4
Before Addition
157 A-7074-229-A PD-117 (N-SH) BOARD,COMPLETE
168 1-803-844-81 DISPLAY PANEL, LIQUID CRYSTAL
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
LCD901 1-803-852-31 INDICATOR MODULE, LIQUID CRYSTAL
0 LED901 1-517-858-11 LIGHT, BACK (TRV87/TRV87P)
0 ND901 1-517-752-31 TUBE, FLUORESCENT,COLD CATHODE
SECTION 6. REPAIR PARTS LIST
6-1. EXPLODED VIEWS
After Addition
For the method of identifying the Type of LCD. refer to page 5-34 for
“1-6. LCD SYSTEM ADJUSTMENT. LCD Type check” of original
Service Manual (9-974-195-11).
A-7074-141-A PD-117(P-VLO) BOARD, COMPLETE (TYPE C)
**************************************
A-7074-229-A PD-117(N-SH) BOARD, COMPLETE (TYPE S)
**************************************
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67/TRV87/TRV87P)
(Ref.No.;10000 Series)
< CAPACITOR >
C5501 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C5503 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5504 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5508 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5509 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C5510 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C5512 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5513 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5514 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C5515 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
C5516 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(TYPE S)
C5516 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
(TYPE C)
C5517 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5518 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5519 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C5520 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
C5521 1-107-682-11 CERAMIC CHIP 1uF 1 16V
C5522 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5523 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5524 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C5527 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5528 1-135-177-21 TANTALUM CHIP 1uF 20% 25V
(TYPE S)
C5529 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C5530 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TYPE S)
C5531 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TYPE S)
C5602 1-125-822-11 TANTAL CHIP 10uF 10% 10V
C5603 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5604 1-164-657-11 CERAMIC CHIP 0.015uF 10% 50V
C5605 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C5606 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
0 C5607 1-131-959-91 CERAMIC CHIP 12PF 10% 3KV
C5608 1-125-822-11 TANTAL. CHIP 10uF 20% 10V
C5704 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5501 1-573-364-11 CONNECTOR, FFC/FPC 24P
CN5501 1-691-362-11 CONNECTOR, FFC/FPC (ZIF) 24P
* CN5502 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
CN5604 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN5701 1-779-893-11 PIN, CONNECTOR (PC BOARD) 8P
CN5702 1-779-064-11 PIN, CONNECTOR (PC BOARD) 12P
CN5703 1-573-346-21 CONNECTOR, FFC/FPC 6P
CN5703 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
* CN5703 1-778-154-21 CONNECTOR, FFC/FPC (ZIF) 6P
CN5704 1-778-508-21 PIN, CONNECTOR (PC BOARD) 6P
CN5705 1-794-050-21 CONNECTOR, FFC/FPC (ZIF) 26P
< DIODE >
D5502 8-713-102-80 DIODE 1T369-01-T8A
D5503 8-719-073-01 DIODE MA111-(K8).S0 (TYPE S)
D5601 8-719-073-01 DIODE MA111-(K8).S0
D5602 8-719-062-44 DIODE PG1112H-TR
< FERRITE BEAD >
FB5502 1-500-329-11 INDUCTOR CHIP 0UH
FB5503 1-500-329-11 INDUCTOR CHIP 0UH
< IC >
IC5501 8-759-660-92 IC RB5P003AM1
IC5502 8-759-660-91 IC LZ9FF424 (TYPE S)
IC5502 8-759-591-93 IC CM7019L3-T4 (TYPE C)
IC5503 8-759-478-92 IC TC7SET04FU(TE85R) (TYPE S)
IC5601 8-759-564-49 IC TC7W53FU(TE12R)
IC5602 8-759-277-98 IC TA75S393F-TE85R
IC5701 8-759-573-02 IC BU9735K-E2
< COIL >
L5501 1-469-525-91 INDUCTOR 10uH
L5504 1-469-525-91 INDUCTOR 10uH
L5505 1-412-956-21 INDUCTOR 27uH
L5601 1-419-387-21 INDUCTOR 100uH
< TRANSISTOR >
Q5501 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q5502 8-729-041-23 TRANSISTOR MGSF1P02LT1 (TYPE S)
Q5503 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
(TYPE S)
Q5504 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
(TYPE S)
Q5505 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
(TYPE S)
Q5506 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
(TYPE S)
Q5601 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q5602 8-729-039-43 TRANSISTOR FP216-TL
Q5603 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q5604 8-729-042-58 TRANSISTOR RN2102F(TPL3)
< RESISTOR >
R5501 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5503 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R5504 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5505 1-216-835-11 METAL CHIP 15K 5% 1/16W
R5506 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
PD-117
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 7 — — 8 —
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
6-1-4. LCD BLOCK ASSEMBLY (TRV MODEL)
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
6-1-4. LCD BLOCK ASSEMBLY (TRV MODEL)
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
157 A-7074-141-A PD-117 (P-VLO) BOARD,COMPLETE
(TYPE C)
157 A-7074-229-A PD-117 (N-SH) BOARD,COMPLETE
(TYPE S)
168 1-803-844-81 DISPLAY PANEL, LIQUID CRYSTAL
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
LCD901 1-803-852-21 INDICATOR MODULE, LIQUID CRYSTAL
(TYPE S)
LCD901 1-803-859-21 INDICATOR MODULE, LIQUID CRYSTAL
(TYPE C)
0 LED901 1-517-858-11 LIGHT, BACK (TRV87/TRV87P)
0 ND901 1-517-752-31 TUBE, FLUORESCENT,COLD CATHODE
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
: Added portion. : Changed portion.
