4-2. TAPE Maintenance Mode (M0)
4-2-5. AUDIO/VIDEO CHECK Mode (C2)
C25 : DPR-119 DIAG INFO
This function informs the result of the self-diagnosis of the
DPR-119 board of BKNW-118. It is displayed when the
BKNW-118 option is installed.
When a failure occurs on the DPR-119 board, this function
guess the default IC but do not specified.
n
“ERROR” may be displayed as the diagnosis result even if
the boards except DPR-119 are defective.
An initialize check and something check are available as
the self-diagnosis function.
. In the initialize check, check the communication of the
communication bus (PAD0-7, STAT0-1, STRB, and CS)
between SY2 CPU on the SS-83 board and IC213 or
IC216 on the DPR-119 board.
Initialization data is transferred from SY2 CPU to each IC.
After that, the initialization data set in each IC is read and
compared with the initialization data transferred at first.
. In the something check, a parity check and FIFO memo-
ry check are performed for the input signals of IC200,
and the result of the self-diagnosis of IC200 is displayed
by reading from SY2 CPU on the SS-83 board.
Target IC for the diagnosis
Screen Target IC
No. display Ref. No. (IC name) Remarks
1 SDTI TX IC213 (CXD8969AR) Initialize check only
2 AU FEED IC106 (CXD211-124Q) Initialize check only
13 V-PACK IC200 (CXD8977R) Something check only
To display the self-diagnosis function result
(1) Select the C25 : DPR-119 DIAG INFO menu.
(2) To scroll the screen, turn the JOG dial.
Downward: Turn it in REVERSE (3) direction.
Upward: Turn it in FORWARD (2) direction.
(3) Press the MENU button to terminate the menu after
checking the self-diagnosis result.
SOMETHING CHECK Target IC (Its pin number)
Screen display [Ref. No. of Connected IC]
15. ECC ENC CHECK. NG
MACRO SEQ ERR IC402 (Data is abnormal)
EXT FIFO FULL WARN
PACK2 NOT FIN ERR
SDRAM ERR IC402, [IC403]
EXT FIFO ERR B IC402, [IC401]
EXT FIFO ERR A IC402, [IC400]
PARITY ERR SX-IN IC402 (Pins 60 to 69), [IC200]
PARITY ERR AUD-0 IC402 (Pin 140)
PARITY ERR AUD-1 IC402 (Pin 141)
16. OUTER CHECK. NG
PARITY ERR xx IC600
(Pins 49, 50, 57 to 59, 62 to 66)
n
On “xx displays the number of the input parity errors.
SDRAM ERR NT IC600, [IC603]
SDRAM ERR JOG IC600, [IC601, IC602]
17. SX DEC CHECK. NG
SDRAM ERR ALL IC800, [IC801, IC802]
n
Displays “ALL” wherever an abnormal point occurs.
PARITY ERR MEP IC800
(Internal connection of IC800)
PARITY ERR STREAM IC800 (Pins 88 to 95, 98, 112)
CLOCK ERR 13.5M IC800
CLOCK ERR 27M (Pins 99, 120 to 124, 127 to 132)
CLOCK ERR 54M
CLOCK ERR 81M
AUDIO/VIDEO CHECK MODE
C25:DPR-119 DIAG INFO
DPR-119 DIAG. OK!
