4-93
DNW-A75/A75P
4-5-3. RESET ALL SETUP Executing Menu (M49)
Reset the following settings to the factory setting at once.
. All “current” and “bank” in the setup menu
For 525/60 system : current, bank1, bank2, bank3, bank4
For 625/50 system : current, bank1, bank2, bank3, bank4
. ITEM-013 : 525/625 SYSTEM SELECT in the setup menu
. M40 : EXTENDED MENU in the maintenance mode
. Shot mark list (Clear the data)
To execute
(1) Turn the search dial while pressing the JOG button, and display “ON”.
. On changing the setting to “ON”, the messages “Push SET Button” and
message “All the System Setup data will be changed to Factory default.” are
displayed on only the superimposed display.
(2) Press the SET button.
. The message “Executing...” is displayed on only the superimposed display
during changing the setting.
(3) Check that the setting change is completed.
. After the setting change is completed, the messages “Complete” and “Turn
off/on POWER!!” are displayed on only the superimposed display.
(4) Turn off the power.
(5) Turn on the power again.
4-5. Setup Maintenance Mode (M4)
4-5-3. RESET ALL SETUP Executing Menu (M49)
Example of display
and operation
0
[JOG] + DIAL
SETUP MAITENANCE MODE
M49 : RESET ALL SETUP
OFF
SETUP MAITENANCE MODE
M49 : RESET ALL SETUP
ON
Push SET Button
------ Caution ------
All the System Setup
data will be changed
to Factory default.
(1)
0
[SET]
(2)
*
*
0
Check
SETUP MAITENANCE MODE
M49 : RESET ALL SETUP
ON
Executing...
------ Caution ------
All the System Setup
data will be changed
to Factory default.
SETUP MAITENANCE MODE
M49 : RESET ALL SETUP
ON
Complete
Turn off/on POWER!!
(3)
0
Turn OFF the power
(4)
0
Turn ON the power
(5)
*
*
To Next Page
