(2) To change the setting, turn the search dial while
pressing the JOG button.
ON 8 OFF: REVERSE (3) direction
OFF 8 ON: FORWARD (2) direction
(3) To change the setting of other categories, repeat steps
(1) and (2).
(4) To finish the setting mode, press the MENU button
once.
Example of display and operation
4-3-3. Setting Mode
The setting mode is used to display a menu that limits the
display of an error log. In this menu, the display can be
turned on and off for each error log category. A calendar/
clock can also be set in this menu.
m
. The top and second screens on the right are the examples
displayed when the error logger mode and setting mode
are first activated after the power is turned on. The
second-time or later screen is displayed with the preced-
ing display completed.
. A white square mark is displayed in the upper-right
position of the superimposed display as in the display
mode when the SET button is pressed in the setting
mode (except when “Push SET Button” is displayed
during calendar/clock setting). The unit then enters the
normal operation state (in which the normal operation of
this unit except a menu system can be performed). The
former state is returned when the MENU button is
pressed.
Entering the setting mode
Press the SET button while pressing the STOP button in
the display mode.
Returning to the display mode
Press the SET button again while pressing the STOP
button or press the MENU button.
Setting menu
The seventh to tenth lines on the superimposed display are
a setting menu. The display in the display mode is left in
the first to fifth lines.
Each setting when the power is turned on is all ON.
The error log belonging to a category is limited in display
when each item is set to OFF. (Refer to the “Limited-
display screen” on the previous page.)
The changed setting is valid until the power is turned off.
How to change the setting is described below.
(1) Turn the search dial to set the * mark to the category
to be changed in setting.
m
. In the time data display area, the contents of the *-
marked line are displayed on the superimposed
display.
. Turn the search dial continuously in FORWARD
(2) direction for the calendar/clock setting. (Refer
to the next page.)
4-3. Error Logger Display Mode (M2)
4-3-3. Setting Mode
ERROR LOGGER
(001/003)
001 REEL TROUBLE-1
002 TAPE TENSION ERROR
003 INTERNAL I/F ERROR
------------------------
TAPE ERROR ON
WARNING ON
CONDITION ON
'98 07 03 09:23:17
ERROR LOGGER
(001/003)
001 REEL TROUBLE-1
002 TAPE TENSION ERROR
003 INTERNAL I/F ERROR
'98 07 03 09:23:15
*
*
0
[STOP] + [SET]
[JOG] + DIAL (3)
[JOG] + DIAL (2)
ERROR LOGGER
(001/003)
001 REEL TROUBLE-1
002 TAPE TENSION ERROR
003 INTERNAL I/F ERROR
------------------------
TAPE ERROR ON
WARNING ON
CONDITION ON
'98 07 03 09:23:20
*
0
DIAL (2)
ERROR LOGGER
(001/003)
001 REEL TROUBLE-1
002 TAPE TENSION ERROR
003 INTERNAL I/F ERROR
------------------------
TAPE ERROR ON
WARNING OFF
CONDITION ON
'98 07 03 09:23:22
*
0
ERROR LOGGER
(001/003)
001 REEL TROUBLE-1
002 TAPE TENSION ERROR
003 INTERNAL I/F ERROR
------------------------
TAPE ERROR ON
WARNING ON
CONDITION ON
'98 07 03 09:23:24
*
0
Display mode
Setting mode
To Next Page
