Sony DNW-A75 - Equipment for Adjustment

2-26
DNW-A75/A75P
2-14. Fixtures and Adjustment Equipment List
2-14-2. Equipment for Adjustment
It is recommended to use the equipment listed below or the equivalents.
Each equipment is available as a standard product.
n
These equipment are used in the maintenance manual part 2.
Equipment Model name Remarks
Analog composite video signal generator Tektronix 1410 (For 525/60 system)
(with GENLOCK mode)
Tektronix 1411 (For 625/50 system)
Analog composite video signal generator Tektronix TSG-170A (For 525/60 system)
Tektronix TSG-271 (For 625/50 system)
Analog component video signal generator Tektronix TSG-300 For generating SMPTE/EBU format analog
video signal
(For DNW-A75)
Tektronix TSG-371 For generating SMPTE/EBU format analog
video signal
(For DNW-A75P)
Digital component video signal generator Tektronix TSG-422 (OP.1S) For generating 4:2:2 format digital signal
Spectrum analyzer Advantest R3261A With external trigger function
Bandwidth: more than 100 MHz
Oscilloscope Tektronix 2465B
Analog component waveform monitor Tektronix WFM300 or WFM300A For measuring analog component video
levels
Serial component waveform monitor Tektronix WFM601
Analog composite waveform/vector monitor Tektronix 1750 or 1780R For measuring analog composite SC-H
(For 525/60 system)
Tektronix 1751 or 1781R For measuring analog composite SC-H
(For 625/50 system)
Audio signal generator Tektronix SG505 (OP.02)
Audio analyzer Tektronix AA501A (OP.02) For measuring levels (dBm), distortion, and
dB ratio
Audio level meter Hewlett-Packard HP3400A
Frequency counter Advantest TR5821AK
Digital voltmeter Advantest TR6845
Monitor with serial digital input Sony BVM-1311 (For DNW-A75)
(with optional accessory BKM-2085-14)
Sony BVM-1411 (For DNW-A75P)
(with optional accessory BKM-2085-14)
Network analyzer Anritsu MS420B
Time code generator Sony BVG-1600 (For 525/60 system)
Sony BVG-1600PS (For 625/50 system)
Time code reader Sony BVG-1500 (For 525/60 system)
Sony BVG-1500PS (For 625/50 system)
Terminator — 75-ohm, BNC type
BNC T adapter — 75-ohm
Recording tape Sony BCT-SX series Cassette tape for Betacam SX
Tension meter Tentelo Meter T2-H7-UMC For measuring tape tension
