Sony DNW-A75 - SERVO CHECK Mode (C00-03)

4-14
DNW-A75/A75P
C0 : SERVO/DT CHECK
C00-03 : SERVO CHECK
C00 : INPUT CHECK
C000 : CASSETTE SW
C001 : CASSETTE COMP. SW
C002 : TOP/END SENSOR
C003 : DEW SENSOR
C01 : MOTOR CHECK
C010 : S REEL MOTOR
C011 : T REEL MOTOR
C012 : THREADING MOTOR
C013 : CASSETTE COMP. MOTOR
C014 : CAPSTAN MOTOR
C015 : DRUM MOTOR
C016 : REEL POSITION MOTOR
C02 : PLUNGER SOLENOID CHECK
C020 : PINCH ROLLER
C021 : S REEL BRAKE
C022 : T REEL BRAKE
C023 : CLEANING ROLLER
C03 : REEL/CAPSTAN MOTOR & FG CHECK
C04 : ANALOG DT CHECK (Describes in Section 4-2-3.)
4-2-2. SERVO CHECK Mode (C00-03)
The C00-03 : SERVO CHECK mode is used to check the servo system. The
underlined menus and submenus in the menu tree below are described next.
n
In the servo check mode, only the menu number is displayed in the time data display
area. (C00-03 is displayed as “C00”.)
Menu Tree of Servo System Check Mode
n
When the unit has a cassette tape, the cassette tape is automatically ejected on
shifting to any lower-level menu from the C00-03 : SERVO CHECK menu.
4-2. TAPE Maintenance Mode (M0)
4-2-2. SERVO CHECK Mode (C00-03)
