1-27
DNW-A75/A75P
1-13-3. System Phase Alignment
An external reference video signal and analog composite signal must be input to this unit after they are
adjusted so that SC-H conforms to the specifications.
When Connecting to a Digital Switcher
Fundamentally, the system phase adjustment is not necessary.
Refer to the manual of digital switcher for details.
When Connecting to an Analog Switcher
Perform the system phase adjustment according to the manual of the analog switcher.
To adjust the system phase of this unit, use the SYNC and SC control knobs of SYSTEM PHASE on the
sub control panel.
m
. Be sure to adjust in PB mode.
The system phase does not change even if the SYNC/SC control is turned in the REC mode, but it
changes when the REC mode is shifted to the PB mode.
. The playback sound may be momentarily interrupted when the SYNC/SC control knob is turned during
tape playback.
1-13-4. Setup Menu Settings
Video/Sync Delay Setting “ITEM-701”
Commonly, when integrating the menu into the editing system, set to “VIDEO”.
To prevent the picture shift during EE/PB switching in the VTR-to-VTR edit operation, this setup menu is
also set to “VIDEO”.
Analog Component Input/Output Format Setting “ITEM-709” (525/60 system only)
Set the input (SUB-ITEM-0) and output (SUB-ITEM-1) sides to “D-1” or “B-CAM” according to the
operating system, respectively.
1-13. Settings and Adjustment when External Equipment is Connected
