Sony DNW-A75 - ROM VERSION Display Menu (M30); SERIAL NUMBER Display Menu (M31)

4-85
DNW-A75/A75P
M3:OTHERS
M30:ROM VERSION
DNW-A75(SYL)
SY1 V1.30 SY2 V1.33
SV1 V1.31 DT V1.00
SY3 V1.00
---Option Boards---
SDTI-CP Output(DPR-150)
*
1
2
3
4-4-2. ROM VERSION Display Menu (M30)
This menu displays the model name of this unit, the
destination, the ROM version, and the information of the
installed option.
Description of superimposed display
1 The model name of this unit and the destination in
parentheses are displayed on the superimposed display.
The model name and destination are detected from the
setting condition of the DIP switch (S1102) on the SS-
83 board.
2 Each version number of system control ROMs (SY1
and SY2), a servo ROM (SV1), and a DT board
control ROM (DT) is displayed on the superimposed
display.
When BKNW-124 is used, a version number of
BKNW-124 control ROM (SY3) is also displayed.
3 The installed option is displayed as described below
when the option is installed.
BKNW-118 8 SDTI (SX) Output (DPR-119)
BKNW-124 8 SDTI-CP Output (DPR-150)
Menu operation
Turn the search dial to move the * mark.
The contents of the *-marked item on the superimposed
display are also displayed in the time data display area.
The installed option is displayed on only the superimposed
display.
4-4-3. SERIAL NUMBER Display Menu (M31)
This menu displays the serial number of this unit. When
each serial number does not coincide because of repair, it
can be set again in this menu.
m
. Set the serial number again after the MS-58 board or the
NV-RAM (IC9 on the MS-58 board) is replaced.
. “-----” is displayed in the state where no serial
number is set.
Serial number setting
(1) Turn the search dial to turn on and off the digit you
wish to set.
(2) Turn the search dial while pressing the JOG button and
change the digit number.
. On changing the serial number, a message “Push
SET Button” will be displayed on only the superim-
posed display.
. To cancel the setting, press the MENU button to
terminate this menu.
(3) Repeat steps (1) and (2) for each digit.
(4) Press the SET button to save the set serial number.
. On pressing, a message “Saving...” will be displayed
on only the superimposed display. If no abnormality
is found, the display changes to “Save Complete”
after a few seconds.
4-4. OTHERS CHECK Mode (M3)
4-4-2. ROM VERSION Display Menu (M30)
4-4-3. SERIAL NUMBER Display Menu (M31)
M3:OTHERS
M31:SERIAL NUMBER
10123
