4-5. Setup Maintenance Mode (M4)
4-5-1. Outline
The setup maintenance mode is used for the setup menu.
This unit has two menus below.
Method to select M49: RESET ALL SETUP
(1) Turn the search dial while pressing the PLAY button and move the “*” mark.
(2) Press the SET button.
4-5-2. EXTENDED MENU Display Selection Menu (M40)
It is selected by switching the DIP switch S1100-1 on the SS-83 board whether
display the extended menus of the setup menu or not.
However, only when this switch is OFF (factory setting), the extended menus are
enabled to display by this menu.
n
When the setting of the DIP switch S1100-1 is ON, the extended menus are enabled
to display regardless of the setting in this menu.
To execute
(1) Turn the search dial while pressing the JOG button, and display the desired
setting.
disable: Not display the extended menu
enable: Display the extended menu
(2) Press the SET button.
SETUP MAITENANCE MODE
M40 : EXTENDED MENU
M49 : RESET ALL SETUP
*
4-5. Setup Maintenance Mode (M4)
4-5-1. Outline
4-5-2. EXTENDED MENU Display Selection Menu (M40)
Example of display
and operation
0
[JOG] + DIAL
SETUP MAITENANCE MODE
M40 : EXTENDED MENU
disable
SETUP MAITENANCE MODE
M40 : EXTENDED MENU
enable
Push SET Button
(1)
0
[SET]
(2)
To Next Page
