4-4. OTHERS CHECK Mode (M3)
4-4-1. Outline
The OTHERS check mode is used for other checks. This unit has the six menus and two submodes (M39
and M3F) below.
OTHERS CHECK mode
Title Page Description
M30 : ROM VERSION 4-85 Displays the unit’s model name, ROM version, and optionally mounted
board.
M31 : SERIAL NUMBER 4-85 Displays and corrects the serial number of this unit.
M32 : RS-232C STATUS 4-86 Displays the interface communication state of an RS-232C connector.
M35 : MEMORY CHECK 4-87 Displays the data in ROM. (Used for check at the factory.)
M36 : HOUR METER RESET 4-87 Displays and resets the resettable hours meter and thread counter.
M37 : METER HEAD ROOM 4-88 Sets the head room of an audio level meter.
M39 : 50PIN DATA ASSIGN 4-88 Sets the 50-pin parallel remote.
M3F : MEMORY CARD UTILITY — Uploads and downloads the software using the memory card box.
M3F : MEMORY CARD UTILITY
M3F:MEMORY CARD UTILITY is the mode which is required to connect the specified tool; memory
card BOX (CDS-20 assembly) when using this mode.
The menu explanation, connection of tool and how to upload/download of software are described in the
maintenance manual part 2, volume-1.
4-4. OTHERS CHECK Mode (M3)
4-4-1. Outline
M3:OTHERS
M30:ROM VERSION
M31:SERIAL NUMBER
M32:RS-232C STATUS
M35:MEMORY CHECK
M36:HOUR METER RESET
M37:METER HEAD ROOM
M39:50PIN DATA ASSIGN
M3F:MEMORY CARD UTILITY
*
To Next Page
