5-12
DNW-A75/A75P
5-2-8. Cassette Compartment and Cassette Supports Cleaning
Notes
. Being careful not to apply an excessive force to the compartment block or mirror,
clean the cassette compartment.
. Do not use an alcoholic chemical in cleaning of the door and mirror to avoid
cracking them.
Tools
. Cloth (or Gauze)
. Vacuum cleaner
Procedure
1. Remove the cassette compartment from the unit. (Refer to Section 2-5.)
2. Remove the dust on the cassette compartment from the cassette insertion inlet
using a vacuum cleaner.
3. Clean the compartment (shaded portion in the figure) using a dry cloth (or
gauze).
n
Do not apply an excessive force to the compartment block.
4. Clean the cassette supports on the mechanical deck using a dry cloth (or gauze).
5. Reattach the cassette compartment. (Refer to Section 2-5.)
5-2. Cleaning
Cassette Compartment Cleaning
Mirror
Compartment block
Cassette compartment block assembly
Cassette support
Cassette supports
Cassette supports
