1-9
DNW-A75/A75P
1-7. Matching Connectors and Cables
When external cables are connected to the connector of this unit, the hardware listed below (or equiva-
lents) must be used.
Panel indication Matching connector (cable) Sony part No.
VIDEO INPUT BNC 75Z, MALE 1-569-370-12
VIDEO OUTPUT BNC 75Z, MALE 1-569-370-12
SDI BNC 75Z, MALE
*1
1-569-370-12
SDTI (OPTION)
*2
BNC 75Z, MALE
*1
1-569-370-12
AUDIO INPUT XLR 3P, MALE 1-508-084-00
AUDIO OUTPUT XLR 3P, FEMALE 1-508-083-00
AUDIO INPUT (AES/EBU) BNC 75Z, MALE
*3
1-569-370-12
AUDIO OUTPUT (AES/EBU) BNC 75Z, MALE
*3
1-569-370-12
TIME CODE IN XLR 3P, MALE 1-508-084-00
OUT XLR 3P, FEMALE 1-508-083-00
MONITOR OUTPUT XLR 3P, FEMALE 1-508-083-00
VIDEO CONTROL D-SUB 15P, FEMALE and 1-561-610-21
JUNCTION SHELL 15P 1-561-929-00
RS-232C D-SUB 9P, FEMALE 1-563-815-21
REMOTE1-IN (9P) 9P remote control cable
(RCC-G series) _
or
D-SUB 9P, MALE and 1-560-651-00
JUNCTION SHEEL 9P 1-561-749-00
REMOTE1-OUT (9P) 9P remote control cable
(RCC-G series) _
or
D-SUB 9P, MALE and 1-560-651-00
JUNCTION SHEEL 9P 1-561-749-00
REMOTE 2 D-SUB 50P, MALE and 1-565-516-11
PARALLEL I/O (50P) JUNCTION SHELL 50P 1-563-379-11
CONTROL PANEL D-SUB 29P cable
*4
_
PHONE
*5
JM-60 stereo phone plug _
*1: Coaxial cable length : max. 200 meters (Reference value based on DNW series)
It is recommended to connect the BELDEN8281 cable or equivalent to this connector.
*2: SDTI (SX) OUTPUT connectors are supplied with optional kit BKNW-118.
SDTI-CP OUTPUT connectors are supplied with optional kit BKNW-124.
*3: Coaxial cable length : max. 600 meters (Reference value based on DNW series)
It is recommended to connect the BELDEN8281 cable or equivalent to this connector.
*4: Supplied with optional control panel extension kit BKNW-122.
*5: It exists on the front (upper control panel).
1-7. Matching Connectors and Cables
