4-91
DNW-A75/A75P
M392 : NV-RAM CONTROL
This menu is used to save the input/output data set in the
50 PIN DATA ASSIGN mode into the NV-RAM.
The current setup data can return to the former saved data
before the change when executing ALL DATA PREVI-
OUS without saving the setup data into the NV-RAM.
n
When the power is turned off without saving the changed
data, the setup data returns to the former saved data.
To execute the menu
(1) Turn the search dial to set the * mark on the superim-
posed display as described below.
To save the setup data after changing:
8 “SAVE ALL DATA”
To return the setup data before changing:
8 “ALL DATA PREVIOUS”
To return the setup data to factory setting, and save
that data:
8 “RESET ALL DATA”
(2) Press the SET button.
. On pressing it, the data transmission is initiated.
. On the superimposed display, a message “Saving ...”
or “Loading ...” will be displayed.
In the time data display area, a message “SAVING”
or “LOADING” will be displayed.
(3) Check to see that the data transmission is completed.
. On completing the data transmission:
On the superimposed display, a message “Save
Complete.” or “Load Complete” will be displayed.
In the time data display area, a message “SAVING”
or “LOADING” will be displayed.
(4) To exit the menu, press the MENU button once.
Example of display and operation
4-4. OTHERS CHECK Mode (M3)
4-4-8. 50PIN DATA ASSIGN Mode (M39)
50PIN DATA ASSIGN
M392:NV-RAM CONTOROL
NO OPERATION
SAVE ALL DATA
ALL DATA PREVIOUS
RESET ALL DATA
*
(1)
0
DIAL (2)
(2)
0
[SET]
50PIN DATA ASSIGN
M392:NV-RAM CONTOROL
NO OPERATION
SAVE ALL DATA
ALL DATA PREVIOUS
RESET ALL DATA
*
*
*
0
50PIN DATA ASSIGN
M392:NV-RAM CONTOROL
NO OPERATION
SAVE ALL DATA
ALL DATA PREVIOUS
RESET ALL DATA
Saving......
(3)
(4)
0
0
Check
[MENU]
50PIN DATA ASSIGN
M392:NV-RAM CONTOROL
NO OPERATION
SAVE ALL DATA
ALL DATA PREVIOUS
RESET ALL DATA
Save Completed
To Next Page
Loading...
