4-90
DNW-A75/A75P
M391 : OUTPUT PIN ASSIGN
This menu changes and resets the output pin setup data.
Also displays the logic level of the input pin.
Description of display
The pin numbers are displayed at the line of “No.”. Also
the right at the pin number is displayed the logic level state
(H;high, L;low).
To change the setup data
(1) Turn the search dial (JOG mode) to set the * mark to
the left side of the data to be changed.
(2) Turn the search dial while pressing the JOG button to
change the data.
FORWARD direction (2): Data value increase
REVERSE direction (3): Data value decrease
n
At the first bite, the data change only area of which
from 00 to 73. If it is required to extend the area of
which from 00 to 0D, turn the search dial while
pressing the EJECT and PLAY buttons simultaneous-
ly.
(3) Repeat steps (1) and (2) for any other data.
(4) To finish the menu, press the MENU button once.
(5) To save the setup data in the NV-RAM, execute the
SAVE ALL DATA in M392 : NV-RAM CONTROL
menu.
Example of display and operation
4-4. OTHERS CHECK Mode (M3)
4-4-8. 50PIN DATA ASSIGN Mode (M39)
50PIN DATA ASSIGN
M391:OUTPUT PIN ASSIGN
No. Command
---+--------------------
10:H 02 02 72 20 00 00
11:H 02 02 72 10 00 00
12:H 01 02 00 20 00 00
13:H 02 02 2B 08 00 00
26:H 02 02 72 08 00 00
27:H 02 02 04 10 00 00
28:H 02 02 01 10 00 00
50PIN DATA ASSIGN
M391:OUTPUT PIN ASSIGN
No. Command
---+--------------------
10:H 02 02 72 20 00 00
11:H 02 02 72 10 00 00
12:H 01 02 00 20 00 00
13:H 02 02 2B 08 00 00
26:H 02 02 72 08 00 00
27:H 02 02 04 10 00 00
28:H 02 02 01 10 00 00
(1)
0
DIAL
(2)
0
[JOG] + DIAL (3)
(4)
(5)
0
0
[MENU]
Data save
*
*
50PIN DATA ASSIGN
M391:OUTPUT PIN ASSIGN
No. Command
---+--------------------
10:H 02 02 72 20 00 00
11:H 02 01 72 10 00 00
12:H 01 02 00 20 00 00
13:H 02 02 2B 08 00 00
26:H 02 02 72 08 00 00
27:H 02 02 04 10 00 00
28:H 02 02 01 10 00 00
*
*
M392:NV-RAM CONTROL
