4-62
DNW-A75/A75P
Example of display and operation
4-2. TAPE Maintenance Mode (M0)
4-2-9. RF ADJUST Mode (A1)
RF ADJUST MODE
A11:EQUALIZER
Auto Adjust (Push SET)
ch RSLT ch RSLT
A1 B1
A2 B2
A5 B5
A6 B6
NA NB
ALL
RF ADJUST MODE
A11:EQUALIZER
Auto Tracking ...
ch RSLT ch RSLT
A1 B1
A2 B2
A5 B5
A6 B6
NA NB
ALL
RF ADJUST MODE
A11:EQUALIZER
Auto Adjusting .......
ch RSLT ch RSLT
A1 B1
A2 B2
A5 B5
A6 B6
NA NB
ALL
(1)
(2)
(3)
0
0
0
0
RF ADJUST MODE
A11:EQUALIZER
Auto Adjust Complete
ch RSLT ch RSLT
A1 OK B1
A2 B2
A5 B5
A6 B6
NA NB
ALL
0
RF ADJUST MODE
A11:EQUALIZER
Auto Adjust Complete
ch RSLT ch RSLT
A1 OK B1 OK
A2 OK B2 OK
A5 OK B5 OK
A6 OK B6 OK
NA OK NB OK
ALL OK
0
0
0
*
A1F:NV-RAM CONTROL
(4)
(5)
(6)
*
*
*
*
*
RF ADJUST MODE
A12:REC CURRENT
Auto Adjust (Push SET)
ch RSLT ch RSLT
A B
ALL
RF ADJUST MODE
A12:REC CURRENT
Auto Adjusting .......
ch RSLT ch RSLT
A B
ALL
RF ADJUST MODE
A12:REC CURRENT
Auto Adjust Complete
ch RSLT ch RSLT
A OK B
ALL
(1)
(2)
(3)
0
0
0
0
RF ADJUST MODE
A12:REC CURRENT
Auto Adjusting .......
ch RSLT ch RSLT
A OK B
ALL
0
RF ADJUST MODE
A12:REC CURRENT
Auto Adjust Complete
ch RSLT ch RSLT
A OK B OK
ALL OK
0
0
0
0
*
A1F:NV-RAM CONTROL
(4)
(5)
(6)
*
*
*
*
*
RF ADJUST MODE
A13:PLAY PLL
Auto Adjust (Push SET)
ch RSLT ch RSLT
A1/5 B1/5
A2/6 B2/6
ALL
RF ADJUST MODE
A13:PLAY PLL
Auto Adjusting
ch RSLT ch RSLT
A1/5 B1/5
A2/6 B2/6
ALL
RF ADJUST MODE
A13:PLAY PLL
Auto Adjust (Push SET)
ch RSLT ch RSLT
A1/5 OK B1/5 OK
A2/6 OK B2/6 OK
ALL OK
(1)
(2)
(3)
0
0
0
0
0
0
0
*
A1F:NV-RAM CONTROL
(4)
(5)
(6)
*
*
*
Insert SR5-1/SR5-1P
Select
[SET]
0
(omitted)
0
Check
[MENU]
Data save
Insert a recording tape
Select
[SET]
Check
[MENU]
Data save
Check
[MENU]
Data save
Insert SR5-1/SR5-1P
Select
[SET]
Ex.: When ALL is selected in
A11 : EQUALIZER
Ex.: When ALL is elected in
A12 : REC CURRENT.
Ex.: When ALL is selected in
A13 : PLAY PLL
