B-2
DNW-A75/A75P
Connector panel
Switch Factory setting Setting
Analog audio input level 600 Z CH1 HIGH ON [||] LOW [||] HIGH OFF [||] HIGH ON
CH2 HIGH ON [||] LOW [||] HIGH OFF [||] HIGH ON
CH3 HIGH ON [||] LOW [||] HIGH OFF [||] HIGH ON
CH4 HIGH ON [||] LOW [||] HIGH OFF [||] HIGH ON
Reference video input 75 Z ON [||] ON [||] OFF
Composite video input 75 Z ON [||] ON [||] OFF
Upper control panel
Switch Factory setting Setting
VIDEO INPUT SDI [||] SDTI (VIDEO & AUDIO) [||] SDI
[||] COMPONENT (Y-R, B) [||] COMPOSITE
AUDIO MIXING CH-1 NOT MIX [||] NOT MIX [||] MIX
([||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4)
CH-2 NOT MIX [||] NOT MIX [||] MIX
([||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4)
CH-3 NOT MIX [||] NOT MIX [||] MIX
([||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4)
CH-4 NOT MIX [||] NOT MIX [||] MIX
([||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4)
AUDIO INPUT CH-1 ANALOG [||] SDI [||] AES/EBU [||] ANALOG
CH-2 ANALOG [||] SDI [||] AES/EBU [||] ANALOG
CH-3 ANALOG [||] SDI [||] AES/EBU [||] ANALOG
CH-4 ANALOG [||] SDI [||] AES/EBU [||] ANALOG
AUDIO MONITOR L CH-1 [||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
R CH-2 [||] CH-1 [||] CH-2 [||] CH-3 [||] CH-4
TC AUTO [||] LTC [||] AUTO [||] VITC
TC GENERATOR INT [||] INT [||] EXT
PRESET [||] PRESET [||] REGEN
REC RUN [||] FREE RUN [||] REC RUN
DF (525/60) [||] DF [||] NDF
VITC ON [||] ON [||] OFF
REMOTE 1 (9P) LOCAL [||] Lighting (REMOTE) [||] Lightless (LOCAL)
REMOTE 2 (50P) LOCAL [||] Lighting (REMOTE) [||] Lightless (LOCAL)
