DNW-A75/A75P
1-8. Signal Inputs and Outputs
Pin No. I/O
**
**
*1
Setting change
**
**
*2
Signal Description
36 IN O REC CLOSURE SW (REC)
37 OUT X REV LAMP REV LAMP STATUS
38 OUT O DA2 PRESET DA2 EDIT PRESET STATUS
39 OUT O DA1 PRESET DA1 EDIT PRESET STATUS
40 OUT X FWD LAMP FWD LAMP STATUS
41 OUT O DA4 PRESET DA4 EDIT PRESET STATUS
42 OUT O DA3 PRESET DA3 EDIT PRESET STATUS
43 OUT X STOP STOP STATUS
44 OUT O VIDEO PRESET VIDEO EDIT PRESET STATUS
45 OUT O INSERT PRESET INSERT EDIT PRESET STATUS
46 OUT X STBY ON STANDBY ON STATUS
47 OUT X PLAY PLAY STATUS
48 OUT X REMOTE REMOTE STATUS
49 OUT X ALARM SYSTEM ALARM STATUS
50 OUT O PREROLL PREROLL STATUS
*1: Input ; 47 kZ pull up to +5 V (close/open)
Output ; 10 kZ pull up to +5 V (0 V or open)
*2: The pins described as O mark are possible to change the setting.
Refer to the optional interface manual for changing the setting.
REMOTE1-IN: 9-pin (female)
REMOTE1-OUT: 9-pin (female)
Pin No. Signal
1 GND
2 RM TX(_)
3 RM RX(+)
4 GND
5 PRIORITY
6 GND
7 RM TX(+)
8 RM RX(_)
9 GND
External view
15
96
RS-232C: 9-pin (male)
Pin No. Signal
1 DCD ; Data Carrier Detect (Input)
2 RXD ; Received Data (Input)
3 TXD ; Transmitted Data (Output)
4 DTR ; Data Terminal Ready (Output)
5 SG ; Signal Ground
6 DSR ; Data Set Ready (Input)
7 RTS ; Request to Send (Output)
8 CTS ; Clear to Send (Input)
9NC
