1-16
DNW-A75/A75P
1-10. Switch and Shorting Plug Settings on PC Boards
Audio input level settings
Channel Ref. No. Display Input level (dBm/600 Z) [ ]: Factory setting Fine adjustment
[+4] 0 _3 _20
CH1 COR100 +4 Short Open Open Open RV100
0 Open Short Open Open
_3 Open Open Short Open
_20 Open Open Open Short
CH2 COR200 +4 Short Open Open Open RV200
0 Open Short Open Open
_3 Open Open Short Open
_20 Open Open Open Short
CH3 COR300 +4 Short Open Open Open RV300
0 Open Short Open Open
_3 Open Open Short Open
_20 Open Open Open Short
CH4 COR400 +4 Short Open Open Open RV400
0 Open Short Open Open
_3 Open Open Short Open
_20 Open Open Open Short
Audio input headroom settings
Channel Ref. No. Display Input headroom (dB) [ ]: Factory setting Fine adjustment
[20] 18 16
CH1 COR101 20 Short Open Open RV100
18 Open Short Open
16 Open Open Short
CH2 COR201 20 Short Open Open RV200
18 Open Short Open
16 Open Open Short
CH3 COR301 20 Short Open Open RV300
18 Open Short Open
16 Open Open Short
CH4 COR401 20 Short Open Open RV400
18 Open Short Open
16 Open Open Short
To Next Page
