1-18
DNW-A75/A75P
Monitor output level settings
Channel Ref. No. Display Output level (dBm/600 Z) [ ]: Factory setting Fine adjustment
[+4] 0 _3 _20
L COR902 +4 Short Open Open Open RV900
0 Open Short Open Open
_3 Open Open Short Open
_20 Open Open Open Short
R COR952 +4 Short Open Open Open RV1000
0 Open Short Open Open
_3 Open Open Short Open
_20 Open Open Open Short
Monitor output headroom settings
Channel Ref. No. Display Output headroom (dB) [ ]: Factory setting Fine adjustment
[20] 18 16
L COR900 20 Short Open Open RV900
18 Open Short Open
16 Open Open Short
R COR950 20 Short Open Open RV1000
18 Open Short Open
16 Open Open Short
Monitor output level switching (fixed or variable)
When the variable level is selected, the level is adjusted with the PHONE level control knob.
Channel Ref. No. Display Monitor output level [ ]: Factory setting
[Fixed] Variable
L COR901 UNITY(L) Short Open
VAR(L) Open Short
R COR951 UNITY(R) Short Open
VAR(R) Open Short
1-10. Switch and Shorting Plug Settings on PC Boards
