4-7
DNW-A75/A75P
C0: SERVO/DT CHECK
This submode is used to check the servo and analog DT systems.
C00-03: SERVO CHECK
This mode is used to check the servo system. For more details, refer to Section 4-2-2 (on page 4-14).
Title Page Description
C00 : INPUT CHECK — Check menu of sensors (not including a part of sensors)
C000 : CASSETTE SW 4-15 Checks the cassette tab and REC inhibit sensors.
C001 : CASSETTE COMP. SW 4-16 Checks the cassette-in and cassette size sensors.
C002 : TOP/END SENSOR 4-17 Checks the tape top and tape end sensors.
C003 : DEW SENSOR 4-18 Checks the dew condensation sensors.
C01 : MOTOR CHECK — Check menu of motors (except a fan motor) and partial sensors
C010 : S REEL MOTOR 4-19 Checks the S reel motor.
C011 : T REEL MOTOR 4-19 Checks the T reel motor.
C012 : THREADING MOTOR 4-20 Checks the threading motor and threading/unthreading end sensors.
C013 : CASSETTE COMP. MOTOR 4-21 Checks the cassette compartment motor and cassette-down sensors.
C014 : CAPSTAN MOTOR 4-22 Automatically checks the capstan motor.
C015 : DRUM MOTOR 4-23 Automatically checks the drum motor.
C016 : REEL POSITION MOTOR 4-24 Checks the reel shift motor and reel position sensors.
C02 : PLUNGER SOL. CHECK — Check menu of solenoids
C020 : PINCH ROLLER 4-25 Checks the pinch roller solenoid.
C021 : S REEL BRAKE 4-26 Checks the S reel brake solenoid.
C022 : T REEL BRAKE 4-26 Checks the T reel brake solenoid.
C023 : CLEANING ROLLER 4-27 Checks the cleaning roller solenoid.
C03 : REEL/CAPSTAN MOTOR & 4-28 Continuous check menu of reel and capstan motors
FG CHECK
C04: ANALOG DT CHECK
This mode is used to check the analog DT system. For more details, refer to Section 4-2-3 (on page 4-29).
Title Page Description
C060 : SG LOOP CHECK 4-29 Checks the feedback loop of the strain gauge for analog Betacam playback.
4-2. TAPE Maintenance Mode (M0)
4-2-1. Overviews
SERVO/DT CHECK
C00-03:SERVO CHECK
C04:ANALOG DT CHECK
*
SERVO CHECK
C00:INPUT CHECK
C01:MOTOR CHECK
C02:PLUNGER SOL. CHECK
C03:REEL/CAPSTAN MOTOR
& FG CHECK
*
[SET]
[MENU]
SERVO/DT CHECK
C00-03:SERVO CHECK
C04:ANALOG DT CHECK
*
ANALOG DT CHECK
C60:SG LOOP CHECK
*
[SET]
[MENU]
