2-51
DSR-70/70P
VIDEO
Black Burst
100 % Full Color Bars
60 % Multi Burst
Bowtie with Mod 10T
Shallow Ramp
Cross Hatch (index)
Line 17
100 % Full Color Bars
Quad Phase
Black Burst
60 % Multi Burst (for Composite)
Mod 10T
Shallow Ramp (B-Y/R-Y OFF)
Cross Hatch (index)
Chroma Noise
Line 17
100 % Full Color Bars
60 % Multi Burst
Mod 10T
Shallow Ramp
100 % Full Color Bars
100 % Full Color Bars (R-Y OFF)
100 % Full Color Bars (B-Y OFF)
Blanking Marker
Line 17 (R-Y OFF)
Line 17 (B-Y OFF)
TIME CODE
(h) (m) (s)
23 : 59 : 00
00 : 00
01 : 00
02 : 00
02 : 30
03 : 00
03 : 30
04 : 00
04 : 40
05 : 20
06 : 00
06 : 40
06 : 45
06 : 50
07 : 50
08 : 20
08 : 50
09 : 20
09 : 50
10 : 20
10 : 50
13 : 50
14 : 50
15 : 20
16 : 20
18 : 00
21 : 00
24 : 00
27 : 00
30 : 00
REC
(s)
60
60
60
30
30
30
30
40
40
40
40
5
5
60
30
30
30
30
30
30
180
60
30
60
100
180
180
180
180
180
No Signal
1 kHz
20 Hz
14.5 kHz
10 kHz
No Signal
1 kHz 0 dBFS
1 ch
2 ch
1 kHz
3 ch
4 ch
No Signal
1 kHz
20 Hz
20 kHz
10 kHz
1 kHz 0 dBFS
1 kHz
32 kHz
4 ch
48 kHz
2 ch
AUDIO
Reference Tape for Alignment (for DVR-70P)
Recording contents of XH5-1AP2 are followings.
*
Audio levels are
__
__
_18 dBFS (Reference), except 1 kHz 0 dBFS part.
