Sony DSBK-150 - SPCK Error Adjustment

8-21 (N)
DSR-70/70P
Conditions for adjustment Adjustment
..
..
. Specification
. EE mode
. VIDEO IN ; 75 % Color bars
TP500/DDE-13 (
*
G-4)
1CT500/DDE-13 (
*
G-4)
Oscilloscope
Spec. A=1.5 ±0.1 Vdc
TSG
130A
VIDEO IN
REF VIDEO INBB
75% CB
DSR-70
8-2-2-21. SPCK Error Adjustment
(Connection)
