Sony DSBK-150 - Maintenance Menu; Menu Structure

4-1
DSR-70/70P
SECTION 4
MAINTENANCE MENU
4-1. MENU STRUCTURE
This unit has a maintenance menu which is used for maintenance.
The maintenance menu has a layered structure through which you move to perform the various checks, settings and
adjustments using the specified menu items. Contents of the maintenance menu are displayed on the LCD monitor and the
time counter of DSR-70/70P.
Values in parenthesis ( ) are time counter display.
MENU, First layer MENU, Second layer MENU, Third layer
MENU DATA CONTROL MENU STATUS DISPLAY (>MENU STA)
(MENU CNT) SAVE MENU DATA (>Save MENU)
LOAD MENU DATA (>Load MENU)
SERVO CHECK (SV Check) SENSOR CHECK (>Sensor) CASS-COMPARTMENT (>>Cass-COM)
TAPE TOP/END (>>Top/End)
HUMID [MOISTURE] (>>HUMID)
REC INHIBIT (>>REC INHI.)
MOTOR CHECK (>Motor) S-REEL (>>S-Reel)
T-REEL (>>T-Reel)
THREADING (>>Threading)
CAPSTAN (>> Capstan)
DRUM (>>Drum)
REEL POSITION (>>Reel POS.)
PLUNGER CHECK (>Plunger) PINCH (>>Pinch)
REEL BRAKE (>>R-Brake)
HEAD CLEANER (>>H. Cleaner)
SERVO ADJUST (SV Adjust) S/T-REEL & CAPSTAN (>Reel & Cap.)
S-REEL ONLY (>S-Reel)
T-REEL ONLY (>T-Reel)
CAPSTAN ONLY (>Capstan)
TENSION (>Tension)
TAPE PATH ADJUST (TP Adjust) TRACKING ADJUST (>Tracking)
RF SWITCHING POSITION (>Switching) X1 MANUAL (>>x1 manual)
AUTO (>>Auto)
ELECTRICAL ADJUST (EL Adjust) PLL F0 (>PLL f0)
DVCAM EQ ADJ (>15 um EQ) MANUAL (>>manual)
AUTO (>>Auto)
DV EQ ADJ (>10 um EQ) MANUAL (>>manual)
AUTO (>>Auto)
REC CURRENT (>REC cur)
FE CHECK (>FE check)
RP DATA INITIALIZE (>RP initial)
BATTERY ADJ (>Batt adj)
SERVICE SUPPORT (Support) ERROR LOG (>Error LOG)
MANUAL EJECT (>Manu. Eject)
DIAGNOSTICS CONTROL (>DIAG CNT) CLEAR ERROR LOG (>>Clear LOG)
OTHERS (Others) SOFTWARE VERSION (>Version)
DSBK-140 SERIAL NO. (>DVIO No.)
MEMORY DISPLAY (>MEM Check) SY MEMORY DISPLAY (>> SY MEM.)
SV MEMORY DISPLAY (>> SV MEM.)
SP MEMORY DISPLAY (>> SP MEM.)
KY MEMORY DISPLAY (>> KY MEM.)
CM DISPLAY (>> CM DISP.)
DATA DISPLAY (>Data Check) SP DATA DISPLAY (>>SP DATA)
