Sony DSBK-150 - S VIDEO out y Level Check

8-9 (N)
DSR-70/70P
Conditions for adjustment Adjustment
..
..
. Specification
. PB mode
75 % Color bars/XH5-1A2
Connection 2
VIDEO OUT 1 (75 Z terminated)
(A) Video Level (B) Sync Level
1RV304/DEN-11 (
*
F-4) 1RV306/DEN-11 (
*
F-3)
TRIG : REF. VIDEO
WFM or Oscilloscope
Spec. A=0.714 ±0.007 V (100 ±1 IRE)
B=0.286 ±0.003 V (40 ±0.5 IRE)
Conditions for adjustment Adjustment
..
..
. Specification
. PB mode
75 % Color bars/XH5-1A2
Connection 2
S VIDEO (Y) OUT (75 Z terminated)
TRIG : REF. VIDEO
WFM or Oscilloscope
Spec. A=0.714 ±0.007 V (100 ±1 IRE)
A
A
B
8-2-2-7. S VIDEO OUT Y Level Check
8-2-2-8. VIDEO OUT 1 Y/SYNC Level Adjustment
