Sony DSBK-150 - COMPONENT y out Level Adjustment

8-7 (N)
DSR-70/70P
Conditions for adjustment Adjustment
..
..
. Specification
. MENU ITEM 713-2, OUTPUT LEVEL ; 7.5 %
. PB mode
75 % Color bars/XH5-1A2
Connection 1
COMPONENT Y OUT (75 Z terminated)
(A) Y/S-Y Level (B) Y/S-Y SYNC
1RV300/DEN-11 (
*
E-1) 1RV307/DEN-11 (
*
F-1)
TRIG : REF. VIDEO
WFM or Oscilloscope
Spec.A=0.714 ±0.007 V (100 ±1 IRE)
B=0.286 ±0.003 V (40 ±0.5 IRE)
Conditions for adjustment Adjustment
..
..
. Specification
. MENU ITEM 713-2, OUTPUT LEVEL ; 7.5 %
. PB mode
75 % Color bars/XH5-1A2
Connection 1
COMPONENT B-Y OUT (75 Z terminated)
1RV301/DEN-11 (
*
F-2)
TRIG : REF. VIDEO
WFM or Oscilloscope
Spec. A=0.700 ±0.007 V (98 ±1 IRE)
A
B
8-2-2-3. COMPONENT Y OUT Level Adjustment
8-2-2-4. COMPONENT B-Y OUT Level Adjustment
