Sony DSBK-150 - COMPONENT R-Y out Level Adjustment

8-8 (N)
DSR-70/70P
Conditions for adjustment Adjustment
..
..
. Specification
. MENU ITEM 713-2, OUTPUT LEVEL ; 7.5 %
. PB mode
75 % Color bars/XH5-1A2
Connection 1
COMPONENT R-Y OUT (75 Z terminated)
1RV302/DEN-11 (
*
F-2)
TRIG : REF. VIDEO
WFM or Oscilloscope
Spec. A=0.700 ±0.007 V (98 ±1 IRE)
Conditions for adjustment Adjustment
..
..
. Specification
. PB mode
75 % Color bars/XH5-1A2
Note : Check that MENU ITEM 713-2,
OUTPUT LEVEL ; 0.0 %
Connection 1
COMPONENT R-Y OUT (75 Z terminated)
TRIG : REF. VIDEO
WFM or Oscilloscope
Spec. A=0.757 ±0.007 V (106 ±1 IRE)
8-2-2-5. COMPONENT R-Y OUT Level Adjustment
8-2-2-6. Setup off Chroma Level Check
