Specifications
Appendixes
136
Appendixes
Video performance
Band width Composite (DSR-70):
30 Hz to 4.2 MHz ±1.0 dB (Y)
Composite (DSR-70P):
25 Hz to 4.8 MHz ±1.0 dB (Y)
S-Video (DSR-70):
30 Hz to 5.0 MHz ±1.0dB (Y),
5.75 MHz +1.0/–3.0 dB (Y) (TM)
S-Video (DSR-70P):
25 Hz to 5.0 MHz ±1.0dB (Y),
5.5 MHz +1.0/–2.0 dB (Y),
5.75 MHz +1.0/–3.0 dB (Y)(TM)
Component (DSR-70):
30 Hz to 5.0 MHz ±1.0 dB (Y),
5.75 MHz +0/–3.0 dB (Y) (TM),
30 Hz to 1.3 MHz ±1.0 dB (C),
1.5 MHz +1.0/–5.0 dB (C)
Component (DSR-70P):
25 Hz to 5.0 MHz ±1.0 dB (Y),
5.5 MHz +1.0/–2.0 dB (Y),
5.75 MHz +1.0/–3.0 dB (Y)
(TM), 25 Hz to 1.5 MHz ±1.0 dB
(C), 2.0 MHz +1.0/–2.0 dB (C)
S/N Composite I/O (Y):
More than 53 dB
S-Video I/O (Y): More than 55 dB
Component I/O (Y):
More than 55 dB
Y/C delay Less than 30 ns
K-factor Less than 2.0% (K2T, KPB)
Processor adjustment range
Video level ±3 dB/–∞ to 3 dB selectable
Chroma level ±3 dB/–∞ to 3 dB selectable
Set up/Black level
±30 IRE/210 mV
Chroma phase ±30˚
Audio performance
Frequency response
2 ch (48 kHz/16 bit):
20 Hz to 20 kHz +0.5/–1.0 dB
4 ch (32 kHz/12 bit):
20 Hz to 14.5 kHz +0.5/–1.0 dB
Dynamic range More than 85 dB
Distortion Less than 0.1%
Input connectors
Digital input
DV IN/OUT (When using DSBK-140 i.LINK/DV
Input/Output Board)
6-pin IEEE1394 connector ×1
SDTI (QSDI) IN (When using DSBK-150 SDTI
(QSDI) Input/Output Board)
BNC type ×1, SDTI (QSDI) format
(270Mbps)
SDI IN (When using DSBK-160 SDI Input/Output
Board)
BNC type ×1, SMPTE 259M, SDI
format (270Mbps)
Analog video input
VIDEO INPUT BNC type ×2 (loop-through),
composite, 1.0 Vp-p, 75 Ω, sync
negative
REF. VIDEO IN BNC type ×2 (loop-through), black
burst, 0.286 Vp-p (DSR-70) or
0.3 Vp-p (DSR-70P), 75 Ω, sync
negative
S VIDEO IN DIN 4-pin ×1
Y: 1.0 Vp-p, 75 Ω, sync negative
C: 0.286 Vp-p (DSR-70) or
0.3 Vp-p (DSR-70P), 75 Ω (burst
level)
Y/R–Y/B–Y (when using DSBK-170 Analog
Component Input/Output Board)
BNC type ×3 (with input/output
selection switch), component
video
Y: 1.0 Vp-p, 75 Ω, sync negative
R–Y: 0.7 Vp-p, 75 Ω (75% for
DSR -70 or 100% for DSR-70P)
B–Y: 0.7Vp-p, 75 Ω (75% for
DSR -70 or 100% for DSR-70P)
Analog audio input
AUDIO INPUT XLR 3-pin (female) ×2
+4/0/–60 dBu, high impedance,
balanced
Timecode input
TC IN BNC type ×1, SMPTE
0.5 to 18 Vp-p, 3.3 kΩ, unbalanced
Output connectors
Digital output
DV IN/OUT (When using DSBK-140 i.LINK/DV
Input/Output Board)
6-pin IEEE1394 connector ×1
Appendixes
Appendixes
137
SDTI (QSDI) OUT (When using DSBK-150 SDTI
(QSDI) Input/Output Board)
BNC type ×1, SDTI (QSDI) format
(270Mbps)
SDI OUT (When using DSBK-160 SDI Input/Output
Board)
BNC type ×1, SMPTE 259M, SDI
format (270Mbps)
Analog video output
VIDEO OUTPUT 1, 2 (SUPER)
BNC type ×2, composite, 1.0 Vp-p,
75 Ω, sync negative
REF. VIDEO OUT
BNC type ×2 (loop-through),
composite sync, 0.286 Vp-p
(DSR-70) or 0.3 Vp-p (DSR-
70P), 75 Ω, sync negative (with
burst)
S VIDEO OUT DIN 4-pin×1
Y: 1.0 Vp-p, 75 Ω, sync negative
C: 0.286 Vp-p (DSR-70) or
0.3 Vp-p (DSR-70P), 75 Ω (burst
level)
Y/R–Y/B–Y (when using DSBK-170 Analog
Component Input/Output Board)
BNC type ×3 (with input/output
selection switch), component
video
Y: 1.0 Vp-p, 75 Ω, sync negative
R–Y: 0.7 Vp-p, 75 Ω (75% for
DSR-70 or 100% for DSR-70P)
B–Y: 0.7Vp-p, 75 Ω (75% for
DSR-70 or 100% for DSR-70P)
Analog audio output
AUDIO OUTPUT
XLR 3-pin (male) ×2, +4/0/–6 dBu
(selectable by menu setting),
600 Ω loaded, low impedance,
balanced
MONITOR AUDIO
Phono jack ×1, –6 dBu, 47 kΩ
load, unbalanced
Headphone output
HEADPHONES Stereo phone jack ×1, –∞ to
–20 dBu, 8 Ω, unbalanced
Timecode output
TC OUT BNC type ×1, SMPTE
2.2 Vp-p±3.0 dB, 600 Ω,
unbalanced
Control connector
REMOTE D-sub 9-pin ×1, for connection
with another DSR-70/70P unit or
other editing control unit,
complied with RS-422A
Power input
DC IN XLR 4-pin (male)
Accessories supplied
Shoulder belt (1)
Connector caps (1 set)
Operating Instructions (1)
ClipLink Guide (1)
Accessories not supplied
DSBK-140 i. LINK/DV Input/Output Board
DSBK-150 SDTI (QSDI) Input/Output Board
DSBK-160 SDI Input/Output Board
DSBK-170 Analog Component Input/Output Board
DSBK-180/180P Dual Video Input Board
BKNW-225 Docking Kit
RCC-5G/10G/30G 9-pin Remote Control Cable (5 m
(16 ft)/10 m (33 ft)/30 m (98 ft) in length )
BP-90A/L60/L60A/L90/L90A Battery Pack
DC-L90/210 Battery Adaptor
BC-210/210CE/410/410CE/L50/L100/L100CE
Battery Charger
AC-DN2/DN2A/550/550CE/CMA-8A/8ACE AC
Adaptor
PDV-64ME/94ME/124ME/184ME Digital Video
Cassette (standard size)
PDVM-12ME/22ME/32ME/40ME Digital Video
Cassette (mini-size)
DV12CL Cleaning Cassette (standard size)
DVM12CL Cleaning Cassette (mini-size)
Related products
DNW-A25/A25P Betacam SX Digital Videocassette
Recorder
ES-7 EditStation
DSR-300/300P Digital Camcorder
Design and specifications are subject to change
without notice.
