Table of Contens
12
Table of Contents
Overview......................................................................... 12
Components of the DSBK-140 .....................................13
Installation...................................................................... 14
Preparations ..................................................................14
Fitting Procedure ..........................................................15
Attaching the Connector Cap........................................18
The DSBK-140 i.LINK/DV Input/Output Board is an optional
board for the DSR-70/70P Sony Digital Videocassette
Recorder. Installing this board in a DSR-70/70P gives the VCR
the capability of being connected to another DSR-70/70P via
an i.LINK/DV
1)
cable to form a cut editing system. The board
also allows the connection of a Sony consumer DV camera for
direct recording and editing.
Refer to the DSR-70/70P Operating Instructions for
information on connecting and operating the DSR-70/70P with
the DSBK-140 installed.
Overview
1)
is a trademark of Sony Corporation and indicates that this product is in
agreement with IEEE1394-1995 specifications and their revisions.
..........................................................................................................................
13
Components of the DSBK-140
The DSBK-140 consists of the following items.
Connector panel
DV-19 board
Harness
6-pin cable
(0.3 m (1 foot))
Connector cap
6-pin/4-pin cable (1 m (3 feet))
To Next Page
