www.spacelabshealthcare.com
1-2
XPREZZON
AND QUBE
O
PERATIONS MANUAL
I NTRODUCTION
Conventions used in this manual
Spacelabs uses specific types of indications to draw your attention to how to use
the monitor.
Reference links are in blue. Place the mouse over the blue text and click the
text, and the topic will be shown. The links are located throughout the manual
and in the
Table of Contents on page I-I.
Bold lettering indicates words, buttons, keys, tabs, and titles that can be found
on the touchscreen. For example: a Home icon is located on the taskbar on the
right of the touchscreen.
Italicized words are references or links to other information. If it is a link to
additional information in the manual, place your cursor over the reference and
click once to bring up that information. It may also be a reference to other
documents available on the CD-ROM.
There are specific steps to accomplish a task that are presented in numbered
steps, possibly followed by the results of the step. The step results are
additional information which may follow the task steps and are shown in gray
typeface. To see an example for the steps, move your cursor to click the
following reference: To install a module on page 1-4.
This Operations Manual is divided into multiple sections. The first section titled
Basic Operations on page 5-1 is a quick reference for basic tasks. The other
sections describe the features in more detail. If the configuration of a feature is
required, it is covered in the XPREZZON
and qube
System Administration
Manual.
Quick Start sections are the steps that explain how to use the various features
and parameters. The Basic Operations on page 5-1 has mostly Quick Start
sections for easy access to doing the basic tasks. The other chapters have
detailed information on the specific features.
Warnings, Cautions and Notes are listed in the priority of the information and
formatted specifically as shown below. Warnings are of the highest priority and
notes are not as serious as the warnings and cautions.
Warning:
Warnings indicate potentially harmful conditions that may lead to injury or
death.
Caution:
Cautions indicate conditions that may lead to damage to or malfunction of the
device.
Note:
Notes alert the user to relevant facts and conditions.
Indications for Use
Spacelabs Healthcare patient monitors, functioning as bedside monitors passively
display data generated by Spacelabs Healthcare parameter modules, Flexports
interfaces, and other SDLC based products in the form of waveform, numeric
displays, trends, and alarms. Key monitored parameters, when employing the

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Spacelabs qube and is the answer not in the manual?

Spacelabs qube Specifications

General IconGeneral
Display TypeLCD
ConnectivityEthernet
Mounting OptionsWall mount, roll stand
Power SourceAC
CompatibilitySpacelabs
Operating Temperature10°C to 40°C
Storage Temperature-20°C to 60°C
Humidity Rangenon-condensing
