www.spacelabshealthcare.com
12-15
XPREZZON AND QUBE
O
PERATIONS MANUAL
M ONITOR SETUP
Numerics
Use the Numerics tab to enable, disable, and change the large numerics format. The
list of parameters may vary with the software version. XPREZZON has three large
numeric formats, and qube has two formats.
Figure 12-9 Numerics tab, qube and XPREZZON
Note:
If Numerics Setup is disabled in Privileged Access/Clinical Setup, the Setup
button is disabled on the Numerics tab.
To select a large numerics format
1 Touch Monitor Setup.
2 Touch the Numerics tab.
3 Touch the display button of the format you prefer under Display
Format.
Button or Key Description
Display Format Select one of the four buttons which offer a different display option. Options
labelled 1, 2, 3 are large numerics displays. The last button on the right
(highlighted in blue) has the large numerics turned off. Refer to
To select a large
numerics format on page 12-15 or Display format tabs on page 12-16 for details.
Setup This button allows the user to configure the large numerics. Refer to To
configure the large numerics format on page 12-16 for information on how to
configure the numerics format you selected.
