www.spacelabshealthcare.com
12-14
XPREZZON
AND QUBE
O
PERATIONS MANUAL
M ONITOR SETUP
To set minimum alarm level that activates the alarm light
1 Touch Monitor Setup.
2 Touch the Setup tab.
3 Under Minimum Alarm Level, touch the desired level.
For example, select High to have the alarm lights activated for
high-priority alarms only. Or select Low to have the alarm lights activated for
all (high, medium, and low) priority alarms.
To enable and adjust minor graticule lines
1 Touch Monitor Setup.
2 Choose one of the following according to whether you want to
change the minor graticule settings on the local monitor or a
remote monitor:
• For the settings on the local monitor, touch the Setup tab.
• For the settings on the remote monitor, touch the Remote Config tab, and
then touch Remote Setup on the lower-right corner of the window. The
Remote Setup window shows.
3 Under Minor Graticule, touch On or Off.
4 Use the up and down arrow keys to adjust the lines from 1 to 6.
The image at the right of the arrow keys shows how the graticule lines will
show for the current setting.
To enable or disable PDL (Optional)
1 Touch Monitor Setup.
2 Touch the Setup tab.
3 Under PDL touch On or Off.
