www.spacelabshealthcare.com
9-9
XPREZZON AND QUBE
O
PERATIONS MANUAL
TRENDS
To add measurements to a category
1 From the Trends Setup window, touch the Tabular tab.
2 Expand the Vitals list by touching the plus sign.
The Measurement Selection list is displayed that shows a list of available
measurements.
3 Touch the category that you want to add measurements to.
If you want to select a different category, use the drop-down list at the top
of the window.
4 Touch Add on the upper-right side of the window.
5 Touch the Show Only Available check box if you want to restrict
the list to measurements that are available for the current
patient.
6 Touch the box in the Selected column for each measurement you want to add
to the category. To select all measurements in a category, select the check
box in the top category row.
7 After you have selected all measurements you want to add, touch OK.
Graphical Trends Setup
With the graphical tabs of the Trends Setup window, you can:
Define graphs.
Add measurements to, or delete them from, the graph.
Rename a graph.
Change the color and scales for a measurement of a graph.
Add reference lines for a measurement on a graph.
Figure 9-4 Graphical tabs in the Trends Setup window
