XPREZZON AND QUBE
O
PERATIONS MANUAL
I NTRODUCTION
Parameter keys
For details on using individual parameter modules, parameter keys and menu keys,
refer to the Clinical Parameters Operations Manual. Parameter keys are located to
the right of the parameter zones on the home screen. Refer to Figure 5-1 on page 5-
2.
Patient Preparation
To prepare a patient for monitoring, attach the lead wires and sensors to the
patient and connect the sensor cables to the module. Touch a parameter key, and
then touch menu options as needed to set up monitoring for a specific parameter.
Refer to Clinical Parameters Operations Manual, and the Module Configuration
Manager System Administration Guide for detailed information on patient
preparation for each module and parameter.
Warnings:
• Use only Spacelabs Healthcare parts and accessories with your Spacelabs
Healthcare products. Other parts and accessories may degrade performance
or damage the components. Refer to the Spacelabs Healthcare Supplies and
Accessories Catalog for the part numbers and descriptions of additional
parts and accessories.
• Do not rely solely on the monitor for critically ill patients.
• Keep patients under close surveillance. Do not rely entirely on the monitor
for patient assessment.
Refer to Basic Operations on page 5-1 for quick reference of basic tasks.
