SPECTRA PRECISION FOCUS 2 SERIES TOTAL STATION USER GUIDE
B – Calculate Road Alignment
159
Transition clothoid (between KA1 and KE1):
ARC (between KE1 and KE2):
Transition (Between KE2 and KA2):
Straight line (between KA2 and BC):
Arc (between BC and EC):
Straight line (between EC and EP):
Radius -100 m (“-”sign is the curve turns left toward the end point)
Length 64 m
Radius -100 m (“-”sign is the curve turns left toward the end point)
Length 131.354 m
Radius -100 m (“-”sign is the curve turns left toward the end point)
Length 64 m
Bearing 322°07’30.1’’
Distance 166.004 m
Radius 200 (without sign is the curve turns right toward the end point)
Length 334.648 m
Bearing 57°59’40.6’’
Distance 250.084 m
