Spectrasensors OXY5500 - Measurement Values Registers

Oxygen Analyzer
4–14 4900002239 rev. G 7-11-17
Measurement Values
Table 4–7 Definition of register 4109
Start
register
Number of
registers
Reg3 / Reg4
Write
Access
4109 2 Int32: Device ID of RS-
232. Minimum 1, Maxi-
mum 32.
Yes
Table 4–8 Definition of register 5695
Start
register
Number of
registers
Reg3 / Reg4
Write
Access
5695 2 Int32: Device ID of
Ethernet. Minimum 1,
Maximum 32.
Yes
Table 4–9 Definition of register 4895
Start
Register
# of
Registers
Reg1/
Reg2
Reg3/
Reg4
Reg5/
Reg6
Reg7/
Reg8
Reg9/
Reg10
Reg11/
Reg12
Reg13/
Reg14
Write
Access
4895 14 Float:
Pres-
sure in
mbar
Float:
Refer-
ence
Ampli-
tude in
mV
Float:
Oxygen
Ampli-
tude in
mV
Float:
Oxy-
gen
Phase
shift in
degrees
Float:
Tempera-
ture in
° C
Float:
Calcu-
lated
Oxygen
Value in
the unit
defined in
register
2089
Int32:
Error Reg-
ister. See
Table 4–10
No
It is not necessary to read out all 14 registers. For simple
applications, reading out registers 9 to 14 (starting with Register
4903) may be all that is required.
