Operation
OXY5500 Operator’s Manual 3
–43
• The Baudrate for the RS-232 channel can be set to 9600, 19200,
38400, 57600 or 115200.
• The ID, which will be used within the Modbus communication, can be
set to any value between 1 and 32.
• Parity can be set to Even, Odd or None.
All settings will be applied by pressing
.
RS-485 settings
Use this screen to set the baudrate of the RS-485 channel. Refer to Figure
3–47.
• The Baudrate for the RS-485 channel can be set to 9600, 19200,
38400, 57600 or 115200.
• The ID, which will be used within the Modbus communication, can be
set to any value between 1 and 32.
• Parity can be set to Even, Odd or None.
Setting the Parity to “None” will also set the number of stop bits
to two. Odd and Even settings will use one stop bit.
Setting the Parity to None will also set the number of stop bits to
two. Odd and Even settings will use one stop bit.
Figure 3–47 Digitals - RS-485 settings
