• “Error code: 1” = No RTD (Pt100) (bit O)
• “Error code: 5” = No RTD (Pt100) and amplitude too low (bit 0 [2
N
Value 1], bit 2 [2
N
Value 4)=5)
• “Error code: 1024” = No pressure sensor connected (bit 10)
• “Error code: 1029” = No RTD (Pt100), amplitude too low, no pressure
sensor connected (bit 0 [2
N
Value 1], bit 2 [2
N
Value 4], bit 10 [2
N
Value 1024] = 1029)
Table 3–2 Error Codes
Bit
2
N
Value
Error
0 1 No RTD (Pt100)
1 2 No sensor selected
2 4 Amplitude too low
3 8 SD card defect
4 16 Reference amplitude out of range
5 32 Photo diode saturated
6 64 Signal overflow
7 128 Signal overflow
8 256 Reserved
9 512 Critical error, contact “Customer Service” on page
B-20
10 1024 No pressure sensor / pressure sensor out of range
11 2048 Reserved
12 4096 Storage space full
