Alternative measurements, setup [Logger, Expert]
ALT measurement means the recording, by manual input with the UP/DOWN keys, of a user
defined quantity in a user defined measuring unit.
In Condmaster
®
Pro, you select ALT 1 and/or ALT 2 as measuring technique. On the data input
form, you enter:
• the measured quantity (flow, pressure, effect, whatever)
• the measuring unit (litres/min, bar, kW, ...)
Both are downloaded to the instrument and displayed.
You also define the range and the scale division of the graphics display in Condmaster
®
Pro. You
can input two lower and two upper alarm limits.
Note: The ALT measuring functions can be used in a wider sense. Instead of recording the values
off meters and dials, you can use them to record ”general condition”: the safety status of a locality
or the genaral mechanical or electrical condition of a part of the plant or a machine. Example:
Meas. point: Safety status, Hall 3
Values: 3 (red alarm) = serious safety hazard, immediate action required.
2 (yellow alarm) = minor faults/risks, fixed by inspector.
1 OK.
Together with the Comment functions, you can thus, with little effort, produce valuable statistics
and reports. Use you imagination!
• Quantity
• Unit
• Format
• Scale
• Upper limit, alert and alarm
• Lower limit, alert and alarm
Alternative measurements 59
