64 Identification tag
Identification tag Cond ID
TM
• Hold the instrument close to the tag
• Press M. The basic measuring point data (and last results) are displayed.
• Take and save all readings, as with a measuring round.
• Option: Hold the instrument close to the tag. Press SET, select WRITE
(the new measuring results are written to the tag).
Identification tag CondID
TM
CondID
TM
is a contact free RF transponder used for measuring point recognition and condition
memory. It is mounted on the adapter cap or strapped in a suitable place on the machine. It should
not be placed directly on metal surface. A distance of min. 3 mm between metal surface and
CondID
TM
is recommended. CondID
TM
is used together with SPM Leonova and the “Logger” and
“Expert” versions of the SPM Tester T30 and Analyzer A30.
CondID
TM
is activated and responds to a recognition signal when an SPM datalogger is held close
to the tag and the M key is pressed. The tag contains all basic data for its measuring point: number,
name, and all measuring techniques connected with it. If the measuring point is already loaded in
the datalogger, it will be fetched and displayed, else it will be added to those in the data logger
memory. CondID
TM
also saves all measuring results when the WRITE function is used after taking
the readings.
The ID tags are made of glass fibre reinforced epoxy , suitable for indoors and outdoors use and
temperatures from -40 to 85 °C.
Press M
to read
Reading distance
max. 50 mm
min. 3 mm
Metal surface
