PM0214 Rev 9 229/262

PM0214 Core peripherals

261

bits you might require more explanation here, and want to remove invalid rows from the

table, and modify the entries in the number of columns.

Determining preemption of an exception uses only the group priority field, see Section 2.3.6:

Interrupt priority grouping on page 41.

Table 51. Priority grouping

PRIGROUP

[2:0]

Interrupt priority level value, PRI_N[7:4] Number of

Binary

point

(1)

1. PRI_n[7:4] field showing the binary point. x denotes a group priority field bit, and y denotes a subpriority

field bit.

Group priority

bits

Subpriority

bits

Group

priorities

Sub

priorities

0b0xx 0bxxxx [7:4] None 16 None

0b100 0bxxx.y [7:5] [4] 8 2

0b101 0bxx.yy [7:6] [5:4] 4 4

0b110 0bx.yyy [7] [6:4] 2 8

0b111 0b.yyyy None [7:4] None 16
