PM0214 Rev 9 231/262
PM0214 Core peripherals
261
4.4.7 Configuration and control register (CCR)
Address offset: 0x14
Reset value: 0x0000 0200
Required privilege: Privileged
The CCR controls entry to Thread mode and enables:
• The handlers for NMI, hard fault and faults escalated by FAULTMASK to ignore bus
faults
• Trapping of divide by zero and unaligned accesses
• Access to the STIR by unprivileged software, see Software trigger interrupt register
(NVIC_STIR) on page 216.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
1514131211109876543210
Reserved
STK
ALIGN
BFHF
NMIGN
Reserved
DIV_0_
TRP
UN
ALIGN_
TRP
Res.
USER
SET
MPEND
NON
BASE
THRD
ENA
rw rw rw rw rw rw
Bits 31:10 Reserved, must be kept cleared
Bit 9
STKALIGN
Configures stack alignment on exception entry. On exception entry, the processor uses bit 9 of
the stacked PSR to indicate the stack alignment. On return from the exception it uses this
stacked bit to restore the correct stack alignment.
0: 4-byte aligned
1: 8-byte aligned
Bit 8
BFHFNMIGN
Enables handlers with priority -1 or -2 to ignore data bus faults caused by load and store
instructions. This applies to the hard fault, NMI, and FAULTMASK escalated handlers. Set this
bit to 1 only when the handler and its data are in absolutely safe memory. The normal use of
this bit is to probe system devices and bridges to detect control path problems and fix them.
0: Data bus faults caused by load and store instructions cause a lock-up
1: Handlers running at priority -1 and -2 ignore data bus faults caused by load and store
instructions.
Bits 7:5 Reserved, must be kept cleared
Bit 4
DIV_0_TRP
Enables faulting or halting when the processor executes an SDIV or UDIV instruction with a
divisor of 0:
0: Do not trap divide by 0
1: Trap divide by 0.
When this bit is set to 0, a divide by zero returns a quotient of 0.
