Core peripherals PM0214

224/262 PM0214 Rev 9

4.4.2 CPUID base register (CPUID)

Address offset: 0x00

Reset value: 0x410F C241

Required privilege: Privileged

The CPUID register contains the processor part number, version, and implementation

information.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Implementer Variant Constant

rrrrrr r r r r rrrrrr

1514131211109876543210

PartNo Revision

rrrrrr r r r r rrrrrr

Bits 31:24 Implementer: Implementer code

0x41: Arm

Bits 23:20 Variant: Variant number

The r value in the rnpn product revision identifier

0x0: revision 0

Bits 19:16 Constant: Reads as 0xF

Bits 15:4 PartNo: Part number of the processor

0xC24: = Cortex-M4

Bits 3:0 Revision: Revision number

The p value in the rnpn product revision identifier, indicates patch release.

0x1: = patch 1
