Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
164
F54—— rear door opening allowed. 2. Setting whether the floor 17-32 (floor sequence) allowed
opening or not. The lowest position corresponds to the rear door of the 17th floor. The
highest position corresponds to the rear door of 32
nd
floor
F55—— rear door opening allowed. 3. Setting whether the floor 33-48 (floor sequence) allowed
opening or not. The lowest position corresponds to the rear door of the 33rd floor. The
highest position corresponds to the rear door of 48
th
floor
F192——rear door opening allowed. 4. Setting whether the floor 49-64 (floor sequence) allowed
opening or not. The lowest position corresponds to the rear door of the 49th floor. The
highest position corresponds to the rear door of 64th floor
Note: For the above 8 parameters, any of which is set as zero, the front or rear door of the
corresponding floor will not open. If any of the above 8 parameters is set as 1, the front
or rear door of corresponding floor will open. For those in group control or parallel
connection, the floor sequence should be in conformity with that of the whole group.
When conducting the above 8 parameter setting, the parameter should be set layer by
layer (bit by bit) on the operator. Therefore, there is no need to calculate the overall
value.
F56—— Upper leveling precision adjustment
F57—— Down leveling precision adjustment
Upper leveling precision adjustment F56 and down leveling precision adjustment F57 is
only aimed at the condition that the precision deviations of every floor leveling are
same.
The specific adjustment method as following: lower F56 for over-leveling when moving
upward. Increase F56 for under-leveling when moving upward, while lower F57 for
over-leveling when moving downward, increase F57 for under-leveling when moving
downward. The setting scope of F56 and F57 ranges from 0 to 100. The default value is
50, which mean no leveling adjustment.
Note: both parameters F56 and F57 are the compensation adjustment for leveling precision.
Common leveling precision deviation within 15mm can be adjusted with F56 and F57.
If the deviation value is too large, it is recommended to adjust the items such as the
leveling switch installation position, drive parameter, hoistway data-study. If the
leveling precision deviation of each floor is not in conformity with each other, the
installation position of leveling plate of the corresponding floor should be adjusted.
F59—— zero-speed band-type brake delay, switch on band-type brake after F59 time upon the
zero speed reached.
F61—— distance between car and destination leveling position when arrival indicator and arrival
gong activated. The data can be used to adjust the time points given by arrival indicator
and arrival gong. The default is 1200, which mean the two signals will be given by car
at about 1.2m away from the destination floor leveling position.
F62—— time limit for anti-slippage operation, the default is 32. If the elevator fails to receive any
leveling signal within 32 seconds, it will stop service, reporting fault NO 25.( the value
is defined by GB7588-2003 as between 20～45 seconds)
F65—— base electrode lock mode, 0: No base electrode lock mode. 1: immediately turn off the
integrated system output once it detect cutoff of output contactor
F67——Without or with extension board
